Name: 25G SFP28 SR Dual LC Transceivers Module Power Source DC 3.3V Compatibility SFP28 MSA for Fiber Optic Equipment
Brand: Hong Kong Starsurge Group Co., Limited
SKU: CC-PMM110L-SD
Availability: InStock

Home > products > Starsurge >

25G SFP28 SR Dual LC Transceivers Module Power Source DC 3.3V Compatibility SFP28 MSA for Fiber Optic Equipment

Place of Origin:

China

Brand Name:

Starsurge

Certification:

RoHS CE FCC UL

Model Number:

CC-PMM110L-SD

Request A Quote

Product Details

Type:

Optical Transceiver

Use:

Network

Warranty Time:

1 Year

Network:

Multi-mode

Port:

Dual LC

Power Source:

DC 3.3V

Connector Type:

Power - Minimum Receivable:

-8.4 DBm (min) / 2.4 DBm (max)

Frequency Range:

850 Nm

Product Name:

CC-PMM110L-SD

Transmission Distance:

OM3-70m / OM4-100m

Operating Temperature Range:

0°C~70°C

Certifications:

SFF-8431, SFF-8432, SFF-8024

Compatibility:

SFP28 MSA

200G QSFP56 Active Optical Cable 26.56GBaud Speed Data Transmission Compatible with OM3/OM4 Connector Type QSFP56 Connector

Get Best Price

video

Data Center Management Interface CMIS 4.0 400G Optical Transceiver with 500m SMF Link

Get Best Price

video

Monitoring Features Temperature and Module Supply Monitoring for 400G QSFP-DD Optical Transceiver in Data Centers HPC

Get Best Price

video

400G QSFP112 SR4 Hot-Plug Multimode Fiber Optic Transceiver 100m Interconnect for Data Centers and Optical Interconnects

Get Best Price

86-186-1839-4729

Elva@cnstarsurge.com

Contact Now

Product Description

25G SFP28 SR Dual LC Transceivers CC-PMM110L-SD

The CC-PMM110L-SD Transceiver is intended for 100m reach service 25.78Gb/s 850nm Multi-mode high-speed communications equipment where low-cost, extraordinary performance and reliability are essential. It consumes low power, operates base on 3.3V DC power supply and is offered in the industrial temperature range. They are compli- ant with SFP28 MSA, SFF-8431 and SFF-8432.

The low jitter and low bit error rate optical assembly features a DML laser transmitter and PIN/TIA receiver. It utiliz- es internal clock and data recovery (CDR) units on transmitter and the receiver chains for low jitter compliance. The differential AC coupled Tx and Rx data interfaces are CML compatible. The device is Class I laser safety compliant.

Standards

• SFF-8024

• SFF-8431

• SFF-8432

• SFF-8472

Features

•25Gbps serial optical interface

•850nm VCSEL transmitter and GaAs PIN PD receiver

•Wide operating temperature(0°C~70°C)

•Maximum link length of 70m via OM3 multimode Fiber (MMF)

•Maximum link length of 100m via OM4 multimode Fiber (MMF)
