Name: 10km Single Mode 25G SFP28 Optical Transceiver Protocol Compliance SFF-8472 Speed LC Connector CE FCC RoHS Certified
Brand: Hong Kong Starsurge Group Co., Limited
SKU: CC-PMM221L-XD
Availability: InStock

Home > products > Starsurge >

10km Single Mode 25G SFP28 Optical Transceiver Protocol Compliance SFF-8472 Speed LC Connector CE FCC RoHS Certified

Place of Origin:

China

Brand Name:

Starsurge

Certification:

RoHS CE FCC UL

Model Number:

CC-PMM221L-XD

Request A Quote

Product Details

Type:

Optical Transceiver

Use:

Network

Warranty Time:

1 Year

Network:

Ethernet, Data Center, High-Speed Switching

Power Source:

DC 3.3V

Connector Type:

Product Name:

CC-PMM221L-XD

Transmission Distance:

10km

Operating Temperature Range:

0°C~+70°C (Commercial), -40°C~+85°C (Industrial)

Protocol Compliance:

SFP28 MSA, SFF-8472, SFF-8402

Package Type:

Hot-Swappable SFP28

200G QSFP56 Active Optical Cable 26.56GBaud Speed Data Transmission Compatible with OM3/OM4 Connector Type QSFP56 Connector

Get Best Price

video

Data Center Management Interface CMIS 4.0 400G Optical Transceiver with 500m SMF Link

Get Best Price

video

Monitoring Features Temperature and Module Supply Monitoring for 400G QSFP-DD Optical Transceiver in Data Centers HPC

Get Best Price

video

400G QSFP112 SR4 Hot-Plug Multimode Fiber Optic Transceiver 100m Interconnect for Data Centers and Optical Interconnects

Get Best Price

86-186-1839-4729

Elva@cnstarsurge.com

Contact Now

Product Description

25G SFP28 10km Transceivers CC-PMM221L-XD

Description CC-PMM221L-XD is intended for 10km reach service from 24.33Gb/s to 25.78Gb/s BI-direction single mode high- speed communications equipment where low-cost, extraordinary performance and reliability are essential. It con- sumes low power, operates base on 3.3V DC power supply and is offered in the industrial temperature range. They are compliant with SFP28 MSA,SFF-8431 and SFF-8432

The low jitter and low bit error rate optical assembly features a DML laser transmitter and PIN/TIA receiver. It utiliz es internal clock and data recovery (CDR) units on transmitter and the receiver chains for low jitter compliance. The differential AC coupled Tx and Rx data interfaces are CML compatible. The device is Class I laser safety compliant.

Applications

Data Center Backbone

Ethernet Switches

High-speed Servers

High-performance Computing

Features

Operating data rate up to 25.78Gbps

Up to 10km transmission on SMF

DFB Laser and PIN-TIA receiver

Build-in dual CDR , for lower EMI

2-wire interface with integrated Digital Diagnostic monitoring

Hot-pluggable SFP28 footprint

Specifications compliant with SFF 8472

Compliant with SFF-8402 with LC connector

Single 3.3V power supply

Power dissipation < 1.2W

Operating temperature range:

Commercial: 0°C to +70°C

Industrial: -40°C to +85°C

Our company is a professional network solution supplier. Based on the information industry, it integrates the research and development of computer network technology and system integration, and provides users with a full range of technical services such as network platforms, system platforms, and application platforms. Show users the solutions of various new network systems and application systems. Our clients cover industries such as government, finance, telecommunications, colleges, transportation,enterprises, hospitals, securities, and public services. The main products include Mellanox, Ruckus,Aruba,Extreme, etc. with favorable prices, rich product catalogs, and perfect after-sales services, the business continues to expand, and customers are all over the United States, South Africa, Europe, East Asia, Russia, and Australia And South America and other countries in the world, has accumulated rich experience in export and customer service. Always to the concept of"quality-oriented, service-oriented", and provide you with cost-effective products and solutions with high-quality professional standards, dedicated attitude and efficient service system. We are committed to building an ecological platform to contribute to the development of information technology!

Q1.What can you buy from us?

Mellanox, Aruba, Starsurge, Rukus, Extreme brand products, including switches, network cards, cables, modules,AccessPoint, etc.

Q2.How about the delivery date?

It usually takes 3-5 working days. For specific models, please contact us to check thestock. In the end, the actual consultation shall prevail. We will do our best to deliver as soon as possible.

Q3.What's your warranty terms?

We supply 12 months warranty time.

Q4.How about the Shipping Method?

We use Fedex/DHL/UPS/TNT and other air shipments,sea shipments are also workable. In one words, we could do any shipments that you wanted.

Q5.Can I get some samples?

Yes, sample order is available for quality check and market test. You only need to pay the sample cost and express cost.

Q6.What are your core strengths?

First-hand supply, Original and new products with the favorable price and perfect after-sales service

Q7.Price questions

The inventory turnover is fast, and the cost of each batch of goods fluctuates according to the market price. The final price is subject to the sales quotation. Please understand.
