Name: Transmission Distance 10km 40Gb/s QSFP LR4 Optical Transceiver 1277.5nm 10km Duplex LC for Speed Fiber Optic Equipment
Brand: Hong Kong Starsurge Group Co., Limited
SKU: CC-QJJCC1L-SD
Availability: InStock

Home > products > Starsurge >

Transmission Distance 10km 40Gb/s QSFP LR4 Optical Transceiver 1277.5nm 10km Duplex LC for Speed Fiber Optic Equipment

Place of Origin:

China

Brand Name:

Starsurge

Certification:

RoHS CE FCC UL

Model Number:

CC-QJJCC1L-SD

Request A Quote

Product Details

Features:

Uncooled 4x10Gb/s CWDM Transmitter, Supports Infiniband SDR, DDR, QDR

Type:

Optical Transceiver

Use:

Data Center Backbone, High-Speed Servers, SAN, Rou

Warranty Time:

1 Year

Network:

Ethernet, Infiniband

Port:

QSFP+

Power Source:

+3.3V ±5%

Connector Type:

LC Duplex

Power - Minimum Receivable:

≤ 1.5W

Transmission Distance:

10km

Data Rate:

40Gbps

Wavelength:

CWDM (1271nm, 1291nm, 1311nm, 1331nm)

Compliance Standard:

IEEE 802.3ba 40GBASE-LR4

Cable Type:

Single-mode Fiber (SMF)

Material:

Metal + Plastic

200G QSFP56 Active Optical Cable 26.56GBaud Speed Data Transmission Compatible with OM3/OM4 Connector Type QSFP56 Connector

Get Best Price

video

Data Center Management Interface CMIS 4.0 400G Optical Transceiver with 500m SMF Link

Get Best Price

video

Monitoring Features Temperature and Module Supply Monitoring for 400G QSFP-DD Optical Transceiver in Data Centers HPC

Get Best Price

video

400G QSFP112 SR4 Hot-Plug Multimode Fiber Optic Transceiver 100m Interconnect for Data Centers and Optical Interconnects

Get Best Price

86-186-1839-4729

Elva@cnstarsurge.com

Contact Now

Product Description

40Gb/s QSFP+ LR4 Optical Transceiver CC-QJJCC1L-SD

This product is a transceiver module designed for 10km optical communication applications. The design is compliant to 40GBASE-LR4 of the IEEE P802.3ba standard. The module converts 4 inputs channels (ch) of 10Gb/s elec trical data to 4 CWDM optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 CWDM channels signals, and converts them to 4 channel output electrical data.

Applications

Data Center Backbone

Ethernet Switches

High-speed Servers

High-performance Computing Clusters

SAN, Routers, Hubs, Load Balancer

Features

Compliant with 40G Ethernet IEEE 802.3ba 40GBASE LR4 standards

Uncooled 4x10Gb/s CWDM transmitter

Supports Infiniband SDR, DDR and QDR

Wide Operating Temperature(0°C~70°C)
