RUCKUS R550 Wi-Fi 6 Access Point High-Density Indoor Wireless AP 1.77Gbps 512+ Clients BeamFlex+ Technology

The RUCKUS R550 represents a significant advancement in indoor wireless technology, specifically engineered to address the challenges of high-density environments. This Wi-Fi 6 (802.11ax) access point delivers exceptional performance, increased capacity, and reliable connectivity for modern enterprise networks requiring robust network card solutions.

• Wi-Fi Standards: IEEE 802.11a/b/g/n/ac/ax
• Concurrent Dual-Band: 2.4GHz and 5GHz operation
• Spatial Streams: 2x2.2 (2.4GHz) + 2x2.2 (5GHz)
• Peak Data Rates: Up to 1,774 Mbps
• Client Capacity: Up to 512 connected devices
• IoT Integration: Built-in BLE and Zigbee radios

The R550 incorporates several proprietary technologies that distinguish it from conventional access points:

• BeamFlex+ Adaptive Antennas: Dynamically selects from up to 64 antenna patterns to optimize signal quality and reduce interference for each connected device
• ChannelFly Dynamic Channel Technology: Employs machine learning to automatically identify and utilize the least congested channels
• SmartMesh Wireless Meshing: Enables self-forming, self-healing mesh networks without complex configuration
• MU-MIMO & OFDMA: Enhances efficiency in high-density environments by serving multiple clients simultaneously

The R550 access point operates by continuously monitoring the RF environment and client connections. Through its adaptive antenna system, it optimizes signal transmission on a per-packet basis, directing radio energy specifically toward connected devices rather than broadcasting uniformly in all directions. This precision targeting significantly improves signal quality while reducing overall interference.

The integrated IoT module allows the access point to function as a converged platform, supporting both Wi-Fi and non-Wi-Fi wireless technologies through a single infrastructure. This network card solution eliminates the need for separate dedicated networks for different wireless protocols.

This wireless access point is ideally suited for medium to high-density indoor environments including:

• K-12 and higher education classrooms
• Enterprise office spaces and conference rooms
• Healthcare facilities and patient care areas
• Hospitality venues and guest accommodations
• Retail spaces and shopping environments

The R550 provides an exceptional network card foundation for organizations requiring reliable, high-performance wireless connectivity that can scale with growing device demands.

The R550 wireless access point delivers several distinct advantages over competing solutions:

• Superior Coverage: BeamFlex+ technology provides up to 50% better coverage compared to standard omni-directional antennas
• Higher Client Density: Supports more than twice the client capacity of previous generation access points
• Future-Proof Design: Integrated IoT capabilities eliminate the need for separate network infrastructure
• Reduced Interference: ChannelFly technology dynamically optimizes channel selection, minimizing co-channel interference
• Simplified Deployment: Multiple management options including cloud, physical, virtual and controllerless deployment

This advanced network card technology ensures reliable performance even in challenging RF environments where traditional access points struggle.

Our company provides comprehensive support services for all our networking products including this high-performance wireless access point:

• Warranty: Limited lifetime warranty on hardware
• Technical Support: 24/7 customer consultation and technical assistance
• Inventory: Over 10 million in stock network components ready for immediate shipment
• Integration Services: Professional technical team available for deployment support

• Ensure proper PoE power budget allocation when planning deployment
• For plenum rated installations, specify model 901-R550-XX00
• Regional variants are available (-US, -WW, -Z2) with country-specific certifications
• Mounting brackets are included for acoustic drop ceiling installation
• Power adapter is not included and must be purchased separately if not using PoE
• Compliance with local RF regulations is required for operation

This network card solution integrates seamlessly with existing infrastructure while providing advanced capabilities for future expansion.
