Premium 100G QSFP28 ZR4 80KM Fiber Optical Transceiver Module for Data Centers
Product Details:
| Place of Origin: | China |
| Brand Name: | own |
| Certification: | CE/FCC/RoHS/UL/TUSUD Mark/ISO9001/ISO1004 |
| Model Number: | 100G QSFP28 ZR4 80KM |
| Document: | CC-QKKLL8L-SD_100G QSFP28 Z...07.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Face to face/bulk price |
| Packaging Details: | outer box |
| Delivery Time: | Spot goods 3-7 days; Customization 2-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Name: | Optical Transceiver Module | Model NO.: | CC-QKKLL8L-SD |
|---|---|---|---|
| Performance: | 100G QSFP28 ZR4 80KM | Speed: | 100G |
| Specification: | 400*265*100mm | Hot-pluggable: | Yes |
| Supply Voltage: | 3.3 V | Operating Case Temperature: | Commercial 0–70 °C; 10G Offers Industrial –40–85 °C Option. |
| Management / Diagnostics: | High-speed: CMIS Rev 5.0+ With I²C; 10G: SFF-8472 DDM With I²C. | Applications: | Data-center Ethernet, HPC/InfiniBand NDR, Cloud/backbone & Metro, Access & Aggregation. |
| Compliance / Environmental: | CE/FCC/UL/TUV /RoHS | Condition: | New |
Product Description
Product Overview
The Optical Transceiver Module CC-QKKLL8L-SD is a high-performance 100G QSFP28 ZR4 transceiver designed for long-haul data transmission. It supports 103 Gbps data rates over single-mode fiber (SMF) with a reach of up to 80 km. Compliant with IEEE 802.3ba and QSFP28 MSA standards, this module integrates advanced cooling EML transmitters and SOA+PIN receivers for reliable operation in demanding environments.
Key Features
- Supports 103 Gbps data rate over 80 km on G.652 SMF
- 4x28Gbps LAN-WDM cooling EML transmitter array
- SOA + PIN and TIA receiver array with high sensitivity
- Digital Diagnostic Monitoring via I²C interface
- Low power consumption: < 7.5W with single 3.3V supply
- Operating temperature: -40°C to +85°C
Technology & Standards
This optical module utilizes LAN-WDM technology with four wavelengths centered at 1295.56 nm, 1300.05 nm, 1304.58 nm, and 1309.14 nm. It complies with QSFP28 MSA, IEEE 802.3ba, and meets Class 1 FDA and IEC60825-1 laser safety standards. The module also supports retimed electrical interfaces for signal integrity.
Working Principle
The transceiver converts electrical signals into optical signals using four EML-based transmitters, each operating at a specific wavelength. These signals are multiplexed and transmitted over a single fiber. On the receiver side, a SOA amplifies the incoming optical signal before it is demultiplexed and converted back to electrical signals by a PIN and TIA array.
Applications
Ideal for 100GBASE-ZR4 Ethernet applications, this Optical Transceiver Module is suited for data centers, telecommunications, and enterprise networks requiring high-speed, long-distance connectivity. It is commonly deployed in backbone networks, metro rings, and inter-data center links.
Specifications
| Parameter | Min | Typ | Max | Unit |
|---|---|---|---|---|
| Data Rate per Lane | 25.78 | Gbps | ||
| Tx Output Power | 2 | 6 | dBm | |
| Rx Sensitivity | -28 | dBm | ||
| Power Consumption | 7.5 | W | ||
| Operating Temperature | -40 | 85 | °C |
Advantages
- Extended reach up to 80 km without repeaters
- High reliability with integrated DDM function
- Low power design reduces operational cost
- Wide temperature range for harsh environments
- Compatible with major switch and router brands
Service & Support
We offer a 3-year warranty, same-day shipping for in-stock items, and 24/7 technical support. Our team provides integration assistance and custom configuration upon request.
FAQ
Q: What is the maximum distance supported?
A: Up to 80 km on single-mode fiber.
Q: Does it support digital diagnostics?
A: Yes, via I²C interface per QSFP28 MSA.
Q: What is the power consumption?
A: Less than 7.5W under full load.
Q: Is it compatible with Cisco/Juniper switches?
A: Yes, it is MSA-compliant and compatible with most major brands.
Precautions
- Use only with compatible QSFP28 ports.
- Avoid bending fiber beyond minimum bend radius.
- Ensure proper ESD protection during handling.
- Do not exceed absolute maximum ratings.
- Comply with local laser safety regulations.
