Integrated Antenna Extreme Networks Access Points AP7532-67030-1 -WR Dual Radio 802.11ac/802.11n 3X3 MIMO

Integrated Antenna Extreme Networks Access Points AP7532-67030-1 -WR Dual Radio 802.11ac/802.11n 3X3 MIMO

3X3 MIMO extreme networks access points

AP7532 extreme networks access points

Integrated extreme ap 7532

Brand Name:


Model Number:



Request A Quote
Product Details
New And Original
Supported Frequency:
5GHz And 2.4GHz
Indoor Access Point
Transmission Standard:
1 Year
Lead Time:
According To Stock
Console Port:
4dBi - 2.4 GHz Band; 6 DBi - 5GHz Band
Product Description

Extreme wireless access points AP-7532-67030-1-WR

Highest Performance Wireless Speeds
3 spatial streams plus 256 QAM modulation support on both the 2.4 GHz and 5 GHz radios deliver the throughput needed to support virtually any enterprise application. The 802.11ac radio delivers up to four times the speed of 802.11n

Easy Migration to 5th Generation 802.11ac Wi-Fi
Easy Migration to 5th Generation 802.11ac Wi-Fi The dual-radio WiNG AP 7532 provides the simplest path to next-generation Wi-Fi. The 802.11ac radio readies you to support new 5 GHz mobile devices, while the 802.11n radio ensures support for all existing mobile devices — including 2.4 GHz clients.

More Robust Wireless Connections
Your users will experience a more robust wireless connection than ever before, thanks to improved beamforming. Beamforming creates the most efficient path for data transmission between an access point and a mobile device. The result is a stronger connection that enables faster data transmission.

Thin and adaptive access points for campus-wide deployments, distributed worksites and remote branch offices Altitude™ Access Points (APs) come in form factors designed for a wide variety of deployment needs ” high-density or high-interference zones, surface or hidden mounts, centralized or independent management. 802.3af Power over Ethernet (PoE) saves installation time and capital expenses by eliminating separate power and data ports/cables, and power injectors and wiring; PoE also frees installers from being forced to locate APs near a power outlet. Plug-and-play installation and remote control greatly reduce the time needed to bring services online. To help eliminate network bottlenecks and system latencies, traffic can be bridged locally at the AP or tunneled to the controller. Sensorless scanning automatically detects unauthorized sessions and rogue devices.


802.11ac Capabilities

• Dual band radios; supports 256-QAM 3X3 MIMO with 3 Spatial Streams

• 20, 40, and 80 MHz Channels

• 1.9 Gbps data rates on dual concurrent radio operations

• Packet Aggregation (AMSDU, AMPDU) Reduced Interface Spacing

• 802.11 • MIMO Power Save (Static and Dynamic) Advanced forward error correction coding: STBC, LDPC

• 802.11ac transmit beamforming Maximal Ratio Combining (MRC)


Layer 3 routing, 802.1q, DynDNS, DHCP server/ client, BOOTP client, PPPoE, and LLDP

Stateful Firewall, IP filtering, NAT, 802.1x, 802.11i, WPA2, WIDs/WIPs, IPSec, RADIUS svr

WMM, WMM-UAPSD, 802.1p, COS, Diffserv. Role-based QoS and packet marking

Radio Specifications

• Wireless Medium: Direct Sequence Spread Spectrum (DSSS), Orthogonal Frequency Division Multiplexing (OFDM), and Spatial Multiplexing (MIMO)

• Network Standards: IEEE 802.11a/b/g/n/ac, 802.11d and 802.11i WPA2, WMM, and WMM-UAPSD, L2TPv3, Client VPN, MESH (released in a future version of WiNG), Captive Portal server

• Data Rates Supported: 802.11b/g: 1,2,5.5,11,6,9,12,18,24,36,48 and 54 Mbps; 802.11a: 6,9,12,18,24,36,48, and 54 Mbps; 802.11n: MCS 0-23 up to 450 Mbps; Turbo mode (256 QAM) on 2.4 GHz band up to 600 Mbps; 802.11ac: MCS 0-9 up to 1.3 Gbps

• Operating Channels: 2.4 GHz band: channel 1 through channel 13 5.2 GHz band: channel 36 through channel 165 *Channel availability depends on local regulatory restriction

• Antenna Configuration: 3X3 MIMO (transmit/receive on both antennas)

• Operating Frequencies: 2412 to 2472 MHz, 5180 to 5825 MHz



The company strictly follows the ISO9001 quality assurance system, and the products are designed, developed and tested in full compliance with advanced international standards. "Internet of Things Management System", "Network Monitoring and Management System", and "Wireless Authentication System" have been widely praised by users in large-scale smart city projects and large-scale system integration projects.

Integrated Antenna Extreme Networks Access Points AP7532-67030-1 -WR Dual Radio 802.11ac/802.11n 3X3 MIMO 0


Q1.What can you buy from us?

A:Mellanox, Aruba, Rukus, Extreme brand products, including switches, network cards, cables, Access Point, etc.

Q2.How about the delivery date?

A:It usually takes 3-5 working days. For specific models, please contact us to check the stock. In the end, the actual consultation shall prevail. We will do our best to deliver as soon as possible.

Q3.What's your warranty terms?

A: We supply 12 months warranty time.

Q4.How about the Shipping Method?

A: We use Fedex/DHL/UPS/TNT and other air shipments,sea shipments are also workable. In one words, we could do any shipments that you wanted.

Q5.Can I get some samples?

A:Yes, sample order is available for quality check and market test. You only need to pay the sample cost and express cost.

Q6.What are your core strengths?

A:First-hand supply, Original and new products with the favorable price and perfect after-sales service.
