MFS1S00-H015V Aoc Active Optical Cable 200Gb/S IB HDR QSFP56 15m

MFS1S00-H015V Aoc Active Optical Cable 200Gb/S IB HDR QSFP56 15m

MFS1S00-H015V Aoc Active Optical Cable

200Gb/S Aoc Active Optical Cable

QSFP56 15m Mellanox AOC

Brand Name:

Mellanox

Model Number:

MFS1S00-H015V

CONTACT US

Request A Quote
Product Details
Availability:
Stock
Warranty:
1 Year
Condition:
New And Original
Technology:
InfiniBand
Type:
Mellanox AOC Cable
Cable Length:
15 Meters
Model:
MFS1S00-H015V
Name:
MFS1S00-H015V MELLANOX Mellanox Active Optical Cable Up To 200Gb/s IB HDR, QSFP56 15m
Keyword:
Mellanox Cable
Product Description

MFS1S00-H015V MELLANOX Mellanox active optical cable up to 200Gb/s IB HDR, QSFP56 15m



 MFS1S00-H015V mellanox AOC cable Product Description



MFS1S00-H015V mellanox AOC cable is a QSFP56 VCSEL-based (Vertical Cavity Surface-Emitting Laser) active optical cable (AOC) designed for use in 200Gb/s InfiniBand HDR systems. The MFS1S00-HxxxE AOC offers high port density and configurability, and a much longer reach than passive copper cables in the data centers. Since the AOC is hot pluggable, it is easy to install and replace. MFS1S00-HxxxE has a standard SFF-8665 compliant QSFP56 port on the electrical side towards the host system. It contains four multi-mode fibers (MMF) optic transceivers per end; each operating at data rates of up to 50Gb/s.

Rigorous production testing ensures the best out-of-the-box installation experience, performance and durability. unique quality active fiber cable solutions provide power-efficient connectivity for data center interconnects. They enable higher port bandwidth, density and configurability at a low cost, and reduced power requirement in the data centers.





MFS1S00-H015V  mellanox AOC cable parameter form





Highlights
Supports IBTA InfiniBand HDR
Up to 200Gb/s data rate
4x 50Gb/s PAM4 modulation
Programmable Rx output amplitude and pre-emphasis
SFF-8665 compliant QSFP56 port
Single 3.3V power supply
4.35W power dissipation (typ., each end with retiming)
Bit Error Rate (BER) better than 1E-15
Up to 150m length
Hot pluggable
RoHS compliant
SFF-8636 compliant I2C management interface





Parameter Value Units
Units 3 ± 0.2 mm
Minimum bend radius 30 mm
Length tolerance 5m ≤ Length < 50m: +500mm /-0 m
Cable color Aqua



Technology InfiniBand
Max Speed HDR
Connector Type QSFP56
Length 15m
stock in stock
