RUCKUS ICX 7550-24ZP Switch High-Density Multigigabit PoE++ with 100G Uplinks
Product Details:
| Brand Name: | Ruckus |
| Model Number: | ICX 7550-24ZP |
| Document: | RUCKUS ICX 7550 Switch Data...et.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Model Number: | ICX 7550-24ZP | Type: | Switch |
|---|---|---|---|
| Brand Name: | Ruckus | Ports: | 12x 2.5G, 12x 2.5/5/10G RJ45, 2x 40/100G QSFP28 |
| Communication ModeSwitching Capacity: | 900 Gbps | PoE Budget: | Up To 1900W |
| Highlight: | ICX7450 Ruckus Network Switch,SFP Ruckus Network Switch,48 Port ruckus icx7450 |
||
Product Description
RUCKUS ICX 7550-24ZP Switch — High-Density Multigigabit PoE++ with 100G Uplinks
1. Product Overview
The RUCKUS ICX 7550-24ZP is a mid-range enterprise-class stackable switch designed to deliver high-performance connectivity and power for modern Wi-Fi 6 and Wi-Fi 7 access points. It features 24 Multigigabit PoE++ ports, including twelve 2.5G and twelve 2.5/5/10G ports, each capable of delivering up to 90W of power. With dual 40/100GbE QSFP28 uplink ports and support for stacking up to 12 units, this switch offers exceptional scalability and future-proofing for demanding network environments.
2. Key Features
- 24 Multigigabit Ethernet ports with IEEE 802.3bt PoE++ (90W per port)
- Dual 40/100GbE QSFP28 uplink/stacking ports
- Up to 1900W total PoE budget with redundant power supplies
- Perpetual PoE and Fast Boot PoE for uninterrupted power delivery
- Advanced Layer 3 routing with BGP, OSPF, VRF, and PIM
- MACsec 256-bit encryption for enhanced security
- Unified management via SmartZone, RUCKUS Cloud, or Unleashed
3. Core Technologies
The ICX 7550-24ZP supports a wide range of industry standards and protocols, including:
- IEEE 802.3bt (PoE++), 802.3bz (Multigigabit), 802.1AE (MACsec)
- IPv4/IPv6 routing with OSPF, BGP, VRRP, PIM, and VRF-lite
- sFlow, SNMPv3, SSH, SCP, TACACS+, RADIUS
- OpenFlow 1.3 for SDN compatibility
- LLDP, QoS, ACLs, and advanced traffic management
4. How It Works
The RUCKUS ICX 7550-24ZP operates as a stackable access or aggregation switch, providing high-speed connectivity and power to connected devices. It uses advanced to handle traffic forwarding and PoE management, while supporting hitless failover and in-service software upgrades (ISSU) for minimal downtime. The switch can be managed centrally via RUCKUS SmartZone or cloud-based platforms, simplifying deployment and ongoing operations.
5. Applications
- Enterprise campus networks with high-density Wi-Fi 6/7 deployments
- Smart buildings with PoE-powered lighting, sensors, and digital signage
- Medium to large-scale VoIP and IP video surveillance systems
- Network aggregation for schools, hospitals, and corporate offices
- Edge switching in distributed environments with fiber backhaul
6. Specifications
| Feature | Specification |
|---|---|
| Ports | 12x 2.5G, 12x 2.5/5/10G RJ45, 2x 40/100G QSFP28 |
| PoE Budget | Up to 1900W |
| Switching Capacity | 900 Gbps |
| Forwarding Rate | 669 Mpps |
| Power Supplies | Dual hot-swappable, 1200W AC (front/back airflow) |
| Dimensions (HxWxD) | 1.73" x 17.32" x 16" |
| Weight | 6.98 kg (15.39 lb) |
| Operating Temperature | 0°C to 45°C |
7. Advantages
- Industry-leading PoE density and power budget
- Future-ready with Wi-Fi 7 support and 100G uplinks
- Flexible stacking with up to 12 units and 10km distance
- Robust security features including MACsec and advanced ACLs
- Multiple management options for on-premises, cloud, or controllerless deployments
8. Service & Support
All RUCKUS ICX switches come with a limited lifetime warranty. We offer 90 days of complimentary technical support, with optional extended support contracts available. Our team provides 24/7 consultation, technical assistance, and global logistics support to ensure seamless integration and operation.
9. Frequently Asked Questions
Q: What is the maximum PoE power per port?
A: Each port supports up to 90W with IEEE 802.3bt PoE++.
Q: Can I stack this switch with other ICX 7550 models?
A: Yes, the ICX 7550 series supports mixed stacking across all models.
Q: Does it support Layer 3 dynamic routing?
A: Yes, with a premium license, it supports OSPF, BGP, and PIM.
Q: What management options are available?
A: SmartZone, RUCKUS Cloud, and Unleashed are all supported.
10. Precautions
- Ensure adequate cooling and airflow in the rack environment.
- Use compatible optics and cables as specified in the RUCKUS transceiver datasheet.
- Verify power capacity and circuit ratings before full PoE deployment.
- Follow local electrical and safety codes during installation.
