Extreme Wireless Access Points PD - 3501G - ENT- E 1port 15.4W IEEE 802.3af indoor PoE 10/100/1000 Mbps module

Extreme Wireless Access Points PD - 3501G - ENT- E 1port 15.4W IEEE 802.3af indoor PoE 10/100/1000 Mbps module

Brand Name:


Model Number:



Request A Quote
Product Details
New And Original
In Stock
Warranty Time:
1 Year
Lead Time:
According To Stock
Number Of Ports:
PoE Output:
Product Description

PowerDsine PD-3501G Features

  • Small and compact design
  • 15 W (15.4 W)
  • Pass through data rates- 10/100/1000 Mbps
  • Fully compatible with IEEE 802.3af standard PoE with an integrated auto-sensing algorithm that provides safe power to remote terminals.
  • Plug-and-play device. Once turned on, it automatically detects the Power over Ethernet terminal and supplies Power over Ethernet
  • Equipped with LED indicator for channel power (Green)


  • Compatible with any IP telephone or IP endpoint device that is compatible with 802.3af Power over Ethernet (PoE)

PD-3501G single-port PoE midspan offers a compact and cost effective, IEEE 802.3af compliant solution for powering IP phones, WLAN access points, network cameras and other IP terminal devices. The compact and affordable PD-3501G provides reliable power over standard Ethernet cables, leaving existing network infrastructure completely unaltered. With plug-and-play installation, the PD-3501G can be easily and cost effectively implemented leveraging the existing Ethernet infrastructure while at the same time providing the assurance of a future proof network.


Feature Description
No. of Ports 1
Data Rates 10/100/1000 Mbps
Power over Ethernet Output Pin Assignment and Polarity: Spare Pairs 7/8 (-) and 4/5 (+) Output Power Voltage: 48 VDC
User Port Power 15.4 Watts (Guaranteed)
Input Power Requirements AC Input Voltage: 100 to 240Vac (±10%) AC Input Current: 0.43A @ 100-240Vac AC Frequency: 50 to 60Hz
Dimensions 51.8mm (W) x 34.8mm (H) x 160.5mm (L) ±0.5mm 2.04 in. x 1.37 in. x 6.31 in ±0.02 in
Weight 44 lbs (200g)
Indicators User Indicator: Channel Power (Green)


Extreme Wireless Access Points PD - 3501G - ENT- E 1port 15.4W IEEE 802.3af indoor PoE 10/100/1000 Mbps module 0


Q1.What can you buy from us?

       A:Mellanox, Aruba, Rukus, Extreme brand products, including switches, network cards, cables, Access Point, etc.

Q2.How about the delivery date?

      A:It usually takes 3-5 working days. For specific models, please contact us to check the stock. In the end, the actual

      consultation shall prevail. We will do our best to deliver as soon as possible.

Q3.What's your warranty terms?

       A: We supply 12 months warranty time.

Q4.How about the Shipping Method?

      A: We use Fedex/DHL/UPS/TNT and other air shipments,sea shipments are also workable. In one words, we could do any

      shipments that you wanted.

Q5.Can I get some samples?

      A:Yes, sample order is available for quality check and market test. You only need to pay the sample cost and express cost.

Q6.What are your core strengths?

      A:First-hand supply, Original and new products with the favorable price and perfect after-sales service.
