Multi Mode AOC Qsfp+ Active Optical Cable Mellanox MFS1S00-H003E

Multi Mode AOC Qsfp+ Active Optical Cable Mellanox MFS1S00-H003E

Multi Mode qsfp+ active optical cable

AOC qsfp+ active optical cable

Mellanox aoc qsfp

Brand Name:

Mellanox

Model Number:

MFS1S00-H003E

CONTACT US

Request A Quote
Product Details
Availability:
Stock
Warranty:
1 Year
Condition:
New And Original
Technology:
InfiniBand
Data Rate:
Up To 200Gb/s
Connector Type:
QSFP56
Length:
20m
Control Input Voltage:
-0.3~4.0V
Product Description

200Gb/s HDR QSFP56 MMF Active Optical Cable



Mellanox® MFS1S00-HxxxE is a QSFP56 VCSEL-based (Vertical Cavity Surface-Emitting Laser) active optical cable (AOC) designed for use in 200Gb/s InfiniBand HDR systems. The MFS1S00-HxxxE AOC offers high port density and configurability, and a much longer reach than passive copper cables in the data centers. Since the AOC is hot pluggable, it is easy to install and replace.



MFS1S00-HxxxE has a standard SFF-8665 compliant QSFP56 port on the electrical side towards the host system. It contains four multi-mode fibers (MMF) optic transceivers per end; each operating at data rates of up to 50Gb/s. MFS1S00-HxxxE offers selectable retiming per lane for both its optical transmitters and receivers up to 50Gbp/s rates.



Rigorous production testing ensures the best out-of-the-box installation experience, performance and durability. Mellanox’s unique quality active fiber cable solutions provide power-efficient connectivity for data center interconnects. They enable higher port bandwidth, density and configurability at a low cost, and reduced power requirement in the data centers.



Highlights
* Up to 200Gb/s data rate
* Programmable Rx output amplitude and pre-emphasis
* Programmable Tx input equalizer
* Selectable retiming
* SFF-8665 compliant QSFP28 port
* Single 3.3V power supply
* 2.2W power dissipation (typ, each end with retiming)
* Low BER
* Up to 100m length
* Hot pluggable
* RoHS compliant
* SFF-8636 compliant I2C management interface



LinkX AOC cables are available in small form-factor pluggable (SFP) and quad small form-factor pluggable (QSFP) and in 10 and 25G non-return-to-zero (NRZ), and 50G-4-level pulse-amplitude-modulation (PAM4) line rates. With 100 percent factory testing in end-to-end configurations, all LinkX AOC cables offer extremely low BER compared to industry standards and competitors. This improves system performance and reliability and ensures optimal signal integrity with the best end-to-end performance.



Light Weight, High Air Flow, Long Reach
LinkX AOC cables are used extensively in cloud and supercomputers due to their low-cost, high-value proposition and increased reliability over connectorized transceivers. LinkX AOCs match the same splitter configurations as direct-attach copper (DAC) cables but are lighter, more flexible, allow more airflow, and support longer reaches, extending up to 30–100 meters. AOCs are used extensively to link NVIDIA GPU-based artificial intelligence systems to Ethernet networks and Ethernet storage fabrics (ESF).



Multi Mode AOC Qsfp+ Active Optical Cable Mellanox MFS1S00-H003E 0


Multi Mode AOC Qsfp+ Active Optical Cable Mellanox MFS1S00-H003E 1
