RUCKUS ICX 7550-48P High-Density Gigabit PoE+ Switch for Enterprise Access and Aggregation
Product Details:
| Brand Name: | Ruckus |
| Model Number: | ICX 7550-48P |
| Document: | RUCKUS ICX 7550 Switch Data...et.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Type: | Switch | Ports: | 48 |
|---|---|---|---|
| Uplink Ports: | 2 X 40G QSFP+ | PoE Budget: | 1900W |
| PoE Standard: | IEEE 802.3at (PoE+) | Warranty: | 1 Year |
| Condition: | Original | ||
| Highlight: | PoE 370W Ruckus Network Switch,ICX7150 Ruckus Network Switch,1000Mbps ruckus icx7150 |
||
Product Description
RUCKUS ICX 7550-48P: High-Density Gigabit PoE+ Switch for Enterprise Access and Aggregation
1. Product Overview
The RUCKUS ICX 7550-48P is a high-performance, stackable, enterprise-grade switch designed for demanding network access and aggregation deployments. It offers 48 Gigabit Ethernet ports with PoE+ support, delivering up to 30W per port and a total PoE budget of 1900W. Ideal for powering Wi-Fi 6/6E access points, IP phones, and IoT devices, this switch also features flexible 40GbE uplinks, advanced Layer 3 routing capabilities, and resilient stacking for scalable network growth.
2. Key Features
- 48 x 10/100/1000 Mbps RJ45 ports with IEEE 802.3at PoE+
- Up to 30W per port, 1900W total PoE budget
- 2 x 40G QSFP+ uplink/stacking ports
- Perpetual PoE and Fast Boot PoE for uninterrupted power
- Stackable with up to 12 units (576 ports per stack)
- Advanced Layer 3 routing (BGP, OSPF, VRRP) with license
- MACsec encryption for enhanced security
- Unified management via SmartZone, RUCKUS Cloud, or Unleashed
3. Core Technologies
The ICX 7550-48P supports a wide range of enterprise networking standards and protocols, including:
- IEEE 802.3at PoE+, 802.1Q VLANs, 802.1X authentication
- IPv4/IPv6 routing with RIP, OSPF, BGP
- MACsec (128/256-bit) for data encryption
- sFlow, SNMPv3, SSH, TACACS+, RADIUS
- OpenFlow 1.3 for SDN compatibility
4. How It Works
The RUCKUS ICX 7550-48P operates as a fully managed Layer 2/3 switch, providing PoE power to connected devices while facilitating high-speed data forwarding. It uses stacking technology to combine multiple physical switches into a single logical unit, simplifying management and enabling hitless failover. Advanced QoS, ACLs, and traffic policing ensure optimal performance for voice, video, and data traffic.
5. Applications
- Enterprise campus access layer for Wi-Fi 6/6E APs
- IP telephony and video surveillance deployments
- IoT and smart building infrastructure
- Medium-density aggregation layer for branch offices
- Educational and healthcare networks requiring high PoE availability
6. Specifications
| Specification | Value |
|---|---|
| Total Ports | 48 x 1G PoE+ RJ45 |
| Uplink Ports | 2 x 40G QSFP+ |
| PoE Budget | 1900W |
| PoE Standard | IEEE 802.3at (PoE+) |
| Switching Capacity | 416 Gbps |
| Forwarding Rate | 309 Mpps |
| Power Supplies | Dual hot-swappable, 1200W AC |
| Dimensions (W x D x H) | 17.32" x 16" x 1.73" |
| Weight | 15.65 lb |
| Operating Temperature | 0°C to 45°C |
7. Advantages
- High PoE density with perpetual power support
- Stackable architecture with 10km distance support
- Future-proof with optional 100G uplinks
- Unified management across wired and wireless networks
- Advanced security features including MACsec and TACACS+
8. Service & Support
All RUCKUS ICX switches come with a limited lifetime warranty. We offer 90-day technical support with optional extended support contracts. Our team provides 24/7 consultation, zero-touch provisioning assistance, and integration services to ensure seamless deployment.
9. Frequently Asked Questions
Q: What is the maximum PoE power per port?
A: Each port supports up to 30W with IEEE 802.3at PoE+.
Q: Can I stack this with other ICX 7550 models?
A: Yes, the ICX 7550-48P can stack with up to 11 other ICX 7550 series switches.
Q: Does it support Layer 3 routing?
A: Yes, with an optional premium license, it supports OSPF, BGP, and VRRP.
Q: Is MACsec included?
A: MACsec support is available with an additional license.
10. Precautions
- Ensure adequate cooling and airflow in the rack environment.
- Verify power capacity and circuit breaker ratings before deployment.
- Use compatible RUCKUS optics and cables for guaranteed performance.
- Follow local electrical and safety codes during installation.
