RUCKUS network switch ICX 7550-24ZP Advanced Multigigabit Stackable Switch for Next-Generation Networks
Product Details:
| Brand Name: | Ruckus |
| Model Number: | ICX 7550-48ZP |
| Document: | RUCKUS ICX 7550 Switch Data...et.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Model Number: | ICX 7550-48ZP | Type: | Switch |
|---|---|---|---|
| Brand Name: | Ruckus | Ports: | 48 |
| Communication Mode: | Full-Duplex & Half-Duplex | Function: | LACP, QoS, SNMP, Stackable, VLAN Support |
| Aggregated Stacking Bandwidth: | 960 Gbps | ||
| Highlight: | 48F RJ45 Ruckus Network Switch,Stackable Ruckus Network Switch,ICX7450 ruckus ethernet switch |
||
Product Description
RUCKUS ICX 7550-24ZP: Advanced Multigigabit Stackable Switch for Next-Generation Networks
The RUCKUS ICX 7550-24ZP is a high-performance, enterprise-class stackable switch designed to meet the demands of modern Wi-Fi 6 and Wi-Fi 7 deployments. It combines high-density multigigabit connectivity with advanced Power over Ethernet (PoE) capabilities, making it an ideal solution for access and aggregation layers in mid-to-large-scale enterprise networks. With support for up to 90W per port PoE, 100GbE uplinks, and flexible stacking options, the ICX 7550-24ZP delivers chassis-like performance with the simplicity and scalability of a stackable switch.
Key Features
- 24 Multigigabit Ethernet ports (12x 2.5G, 12x 2.5/5/10G) with 802.3bt PoE++
- Up to 90W per port PoE with 1900W total PoE budget
- Dual 40/100GbE QSFP28 uplink/stacking ports
- Support for advanced Layer 3 routing (BGP, OSPF, VRF)
- MACsec encryption for enhanced security
- Perpetual and Fast Boot PoE for uninterrupted power delivery
Technology
The ICX 7550-24ZP leverages cutting-edge technologies including IEEE 802.3bt PoE, MACsec 256-bit encryption, and advanced stacking capabilities with up to 12 switches per stack. It supports OpenFlow 1.3 for SDN integration and offers comprehensive Layer 3 routing protocols including OSPF, BGP, and VRF.
How It Works
The switch operates as a standalone or stacked unit, providing high-speed connectivity and power to connected devices. It uses hardware-based forwarding engines to ensure low latency and high throughput. PoE ports deliver power even during switch reboots, ensuring continuous operation for critical devices like APs and IoT endpoints.
Applications
- Enterprise campus networks
- Wi-Fi 6/7 access point aggregation
- Smart buildings with PoE lighting and signage
- High-density wireless deployments
- Data center edge connectivity
Specifications
| Attribute | Value |
|---|---|
| Model | ICX 7550-24ZP |
| Ports | 12x 2.5G, 12x 2.5/5/10G RJ45, 2x 40/100G QSFP28 |
| PoE Standard | 802.3bt (90W per port) |
| PoE Budget | 1900W |
| Switching Capacity | 900 Gbps |
| Forwarding Rate | 669 Mpps |
| Stacking | Up to 12 switches, 10km distance |
| Dimensions (HxWxD) | 1.73" x 17.32" x 16" |
| Weight | 15.39 lb |
| Power Supplies | Dual hot-swappable, 1200W AC |
Advantages
- Future-proof design with Wi-Fi 7 readiness
- Industry-leading PoE density and power budget
- Flexible stacking with 100GbE capabilities
- Advanced security features including MACsec
- Unified management via SmartZone, Cloud, or Unleashed
Service & Support
All RUCKUS ICX 7550 switches come with a limited lifetime warranty. We offer 90-day technical support with optional extended support contracts. Our team provides 24/7 consultation and technical assistance to ensure seamless integration and operation.
FAQ
Q: What is the maximum PoE power per port?
A: The ICX 7550-24ZP supports up to 90W per port using IEEE 802.3bt.
Q: Can I stack this switch with other ICX 7550 models?
A: Yes, all ICX 7550 series switches can be stacked together, up to 12 units per stack.
Q: Does it support Layer 3 routing?
A: Yes, with a premium license, it supports BGP, OSPF, VRF, and more.
Q: What management options are available?
A: SmartZone, RUCKUS Cloud, and Unleashed are all supported.
Q: Is MACsec encryption available?
A: Yes, MACsec 128-bit and 256-bit encryption are supported with a license.
Precautions
- Ensure adequate cooling and airflow in the rack environment.
- Use only compatible RUCKUS optics and power supplies.
- Verify PoE load calculations before deployment.
- Follow local electrical and safety regulations during installation.
