Extreme Network Switch X440 Series Switch X440-G2-24p-10ge4 Extreme Xos

Extreme Network Switch X440 Series Switch X440-G2-24p-10ge4 Extreme Xos

Brand Name:

Extreme

Model Number:

X440-G2-24P-10GE4

CONTACT US
Request A Quote
Product Details
Model NO.:
X440-G2-24p-10GE4
Transmission Rate:
10/100/1000Mbps
Ports:
24
Operating System:
Extreme Xos
L3:
WLAN/STP/Lldp/Lacp
Poe:
380W
Transport Package:
Carton
Specification:
305× 440 × 43.94mm
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
Negotiable
Packaging Details
carton
Delivery Time
7-10days
Payment Terms
T/T
Supply Ability
10000pcs/month
Product Description

Product Description


Extreme Network Switch X440 Series Switch X440-G2-24p-10ge4 Extreme Xos 0
Scalable Cost-Effective Campus Edge Switch
The X440-G2 Series is a scalable, cost-effective family of stackable edge switches designed for campus edge applications. Each X440-G2 model is powered by one of Extreme's flagship operating systems, ExtremeXOS, a resilient OS providing continuous uptime as well as manageability and operational efficiency to the campus edge. The X440-G2 Series switches provide high-performance routing and switching,flexible stacking, PoE support, and comprehensive security.
Available in 12, 24, and 48-port Gigabit Ethernet models with options for SFP and 100BASE-FX fiber models, the X440-G2 Series enable fine-grained control over traffic flows as well as controlled access to network services and applications by supporting intelligent Layer 2 switching and Layer 3 IPv4 or IPv6 routing, as well as a role-based access policy, bi-directional Access Control Lists, and granular ingress and egress bandwidth control.
Highlights

• 12, 24, and 48-port models with Gigabit Ethernet connectivity
• 4x 1Gb uplinks upgradeable to 10Gb
• 30W Power over Ethernet (PoE) support for powering edge devices
• Intuitive and centralized cloudbased network management with
ExtremeCloudTM IQ and ExtremeCloud IQ – Site Engine
• Automated connectivity to Extreme Fabric Connect for simplified and secure network fabric services
• Choice of AC or DC power option
• Non-blocking, wire-speed design
• Stackable with up to eight switches with 40Gb per unit
• SFP and 100BASE-FX fiber model options

Flexible 10Gb Upgrades
All X440-G2 base models come equipped with 4 upgradeable 1Gb ports,
resident on either the faceplate or rear panel of each model. Additional
software licensing is required to upgrade to 10Gb Ethernet, allowing
administrators to increase their switch's uplink speeds without replacing
the entire switch.

High-Performance Stacking
X440-G2 models support high-speed stacking when running ExtremeXOS
SummitStack-V via its two built-in 10Gb ports. Up to eight switches can
be stacked, providing 40Gb per unit and allowing use of standard 10Gb
Ethernet cabling and optics technologies for up to 40 km of connectivity

Power over Ethernet (PoE)
The X440-G2 Series includes 12, 24, and 48-port models supporting PoE
that conform with IEEE 802.3at and IEEE 802.3af, enabling them to
connect to standards-compliant PoE devices. X440-G2 48-port models
are capable of supporting full 30W PoE power across all 48 ports when
deployed with an external redundant power supply (RPS).

Role-Based Policy
X440-G2 models support role-based policies administered through the
ExtremeControl policy manager. This policy framework allows your network
administrators to define distinct roles or profiles to match your enterprise's
operational groups. These defined roles can be granted access to your
chosen network services or applications and enforce access privileges
within both wired and wireless network access points

Audio Video Bridging (AVB)
The X440-G2 Series supports IEEE 802.1 Audio Video Bridging (AVB).
This allows X440-G2 models to enable reliable, real-time audio/video
transmission over Ethernet, meeting the quality of service required for
today's high-definition, time-sensitive multimedia streams.

Cloud-Based Network Management
The X440-G2 Series can be managed by ExtremeCloud IQ and
ExtremeCloud IQ – Site Engine for centralized cloud-based network
management, giving you a consolidated view of users, devices, and
applications for wired and wireless networks for efficient inventory and
network topology management.
ExtremeCloud IQ enables zero touch provisioning, allowing you to quickly
bring new X440-G2 switches online as well as enable the selection of
the OS persona. Alternatively, X440-G2 on-box management can be done
manually via a web-based GUI or generic command-line interface (CLI).
Performance and Scaling

Switch Model
Maximum 10/100/1000 BASE-T Ports
Maximum Active 1Gb SFP Ports
Maximum 10Gb SFP+
Ports
Aggregated Switch Bandwidth*
Frame Forwarding
Rate*
X440 - G2 - 12t - 10GE4
12
4
4 via license
104Gbps
77.4Mpps
X440 - G2 - 24t - 10GE4
24
8(+ 4 Combo)
4 via license
128Gbps
95.2Mpps
X440 - G2 - 48t - 10GE4
48
8(2 + 6 Combo)
4 via license
176Gbps
130.9Mpps
X440 - G2 - 12p - 10GE4
12
4
4 via license
104Gbps
77.4Mpps
X440 - G2 - 24p - 10GE4
24
8(+ 4 Combo)
4 via license
128Gbps
95.2Mpps
X440 - G2 - 48p - 10GE4
48
8(2 + 6 Combo)
4 via license
176Gbps
130.9Mpps
X440 - G2 - 24t - 10GE4 - DC
24
8(+ 4 Combo)
4 via license
128Gbps
95.2Mpps
X440 - G2 - 48t - 10GE4 - DC
48
8(2 + 6 Combo)
4 via license
176Gbps
130.9Mpps
X440 - G2 - 24x - 10GE4
4 Combo
28(24 + 4 Combo)
4 via license
128Gbps
95.2Mpps
X440 - G2 - 24fx - GE4
24100 BASE - FX
4
0
12.8Gbps
9.5Mpps
X440 - G2 - 12t8fx - GE4
12 10/100/1000 + 8 100BASE - FX
4
0
33.6Gbps
25.0Mpps
X440 - G2 - 24t - GE4
24 10/100/1000
4
0
56Gbps
41.7Mpps






2 10GBase-T combo ports

* With 10Gb licenses if available with license
• Less than 4 microsecond latency (64-byte)
• Layer 2/MAC Addresses: 16K
• IPv4 LPM Entries: 480
• IPv4 Hosts: 1000
• IPv6 LPM (64-bit) Entries: 240
• 4096 user-created VLAN/VMANs *
• 9216 Byte Max Packet Size (Jumbo Frame)
• 128 load sharing trunks, up to 8 members per trunk
• 1,024 ingress bandwidth meters, 256 egress meters
• Ingress and egress bandwidth policing/rate limiting per
flow/ACL
• 8 QoS egress queues/port
• Egress bandwidth rate shaping per egress queue and per port
• Rate Limiting Granularity: 8 Kbps




External Ports and Slots
• Half-duplex 10/100 supported on the following 10/100/1000
ports:
•12 port switches: Ports 1-12
•24 port switches: Ports 1-16
• 48 port switches: Ports 1-16 and Ports 25-40
• LRM support on rear-panel SFP/SFP+ ports on all 48-port
switches
• Policy Capabilities
• Policy Profiles: 63
• Rules per Profile: Up to 440
• Authenticated Policy Users per Switch: Up to 1,536
• Authenticated Policy Users per Port: Up to 1,536
• Unique Permit/Deny Rules per switch: 440
• MAC Rules: N/A
• IPv4 Rules: 256
• IPv6 Rules: N/A
• L2 Rules: 184
• Rate Limiting: Per Class of Service
Switch Hardware
Ports
40 - G2 - 12t - 10GE4
- 12 x 10/100/1000BASE - T (RJ - 45)
- 4 x 1GBASE - X SFP (unpopulated front - panel ports) upgradable to 10Gb Ethernet via licensing
- 1 x Serial (console port RJ - 45) with RTS/CTS modem control
- 1 x 10/100/1000BASE - T out - of - band management port
- Coaxial Barrel Connector RPS port
X440 - G2 - 24t - 10GE4
- 24 x 10/100/1000BASE - T (RJ - 45)
- 4 x 1GBASE - X SFP (unpopulated) combo ports
- 4 x 1GBASE - X SFP (unpopulated rear - panel ports) upgradable to 10Gb Ethernet via licensing
- 1 x Serial (console port RJ - 45) with RTS/CTS modem control
- 1 x 10/100/1000BASE - T out - of - band management port
- 2 x 7 RPS port
X440 - G2 - 48t - 10GE4
- 48 x 10/100/1000BASE - T (RJ - 45)
- 4 x 1GBASE - X SFP (unpopulated) combo ports
- 2 x 1GbE copper combo ports upgradable to 10GbE on rear - panel
- 4 x 1GBASE - X SFP (unpopulated rear - panel ports) upgradable to 10Gb Ethernet via licensing
- 1 x Serial (console port RJ - 45) with RTS/CTS modem control
- 1 x 10/100/1000BASE - T out - of - band management port
- 2 x 7 RPS port
X440 - G2 - 12p - 10GE4
- 12 x 10/100/1000BASE - T PoE - Plus
- 4 x 1GBASE - X SFP (unpopulated front - panel ports) upgradable to 10Gb Ethernet via licensing
- 1 x Serial (console port RJ - 45) with RTS/CTS modem control
- 1 x 10/100/1000BASE - T out - of - band management port
- 2 x 7 RPS port
X440 - G2 - 24p - 10GE4
- 24 x 10/100/1000BASE - T PoE - Plus
- 4 x 1GBASE - X SFP (unpopulated) combo ports
- 4 x 1GBASE - X SFP (unpopulated rear - panel ports) upgradable to 10Gb Ethernet via licensing
- 1 x Serial (console port RJ - 45) with RTS/CTS modem control
- 1 x 10/100/1000BASE - T out - of - band management port
- 2 x 7 RPS port
X440 - G2 - 48p - 10GE4
- 48 x 10/100/1000BASE - T PoE - Plus
- 4 x 1GBASE - X SFP (unpopulated) combo ports
- 2 x 1GbE copper combo ports upgradable to 10GbE on rear - panel
- 4 x 1GBASE - X SFP (unpopulated rear - panel ports) upgradable to 10Gb Ethernet via licensing
- 1 x Serial (console port RJ - 45) with RTS/CTS modem control
- 1 x 10/100/1000BASE - T out - of - band management port
- 2 x 9 RPS port
X440 - G2 - 24t - 10GE4 - DC
- 24 x 10/100/1000BASE - T (RJ - 45)
- 4 x 1GBASE - X SFP (unpopulated) combo ports
- 4 x 1GBASE - X SFP (unpopulated rear - panel ports) upgradable to 10Gb Ethernet via licensing
- 1 x Serial (console port RJ - 45) with RTS/CTS modem control
- 1 x 10/100/1000BASE - T out - of - band management port
- 2 x 7 RPS port
