16530 Extreme Switch X440 G2 Extreme Networks AVB 12T 10GE4 new and original
Product Details:
| Brand Name: | Extreme |
| Model Number: | 16530 X440-G2-12t-10GE4 AVB |
| Document: | x440-g2-data-sheet.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Delivery Time: | Based on inventory |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Condition: | New And Original | Availability: | Stock |
|---|---|---|---|
| Warranty Time: | 1 Year | Lead Time: | According To Stock |
| Maximum 10/100/1000 Base-T Ports: | 12 | Maximum Active 1Gb SFP Ports: | 4 |
| Maximum 10Gb SFP+ Ports: | 4 Via License | Aggregated Switch Bandwidth: | 104 GBPS |
| Highlight: | extreme switch x440 16530,10GE4 extreme switch x440,10GE4 extreme networks avb |
||
Product Description
Extreme Networks X440-G2-12t-10GE4 AVB | 12-Port Gigabit Ethernet Switch
The Extreme Networks X440-G2-12t-10GE4 is a high-performance, scalable edge switch designed for modern enterprise networks. It features 12 x 10/100/1000BASE-T ports, 4 x 1GbE SFP ports upgradeable to 10GbE via software license, and support for Audio Video Bridging (AVB). Built with the modular ExtremeXOS operating system, it offers advanced Layer 2/3 switching, PoE+ support, and cloud management capabilities via ExtremeCloud™.
Key Features
- 12 x Gigabit Ethernet RJ-45 ports + 4 x SFP uplink ports (upgradable to 10GbE)
- ExtremeXOS OS with advanced security and management features
- Audio Video Bridging (AVB) support for real-time multimedia streaming
- Role-based policy enforcement and cloud management via ExtremeCloud™
- Energy Efficient Ethernet (EEE) and redundant power support
Technology & Standards
The X440-G2 series supports a wide range of IEEE standards including 802.3ab (1000BASE-T), 802.3z (1000BASE-X), 802.3ae (10GBASE-X), 802.3at (PoE+), and 802.1 Audio Video Bridging (AVB). It also features SummitStack-V stacking technology, allowing up to 8 switches to be stacked with standard 10GbE optics.
How It Works
The switch operates at both Layer 2 and Layer 3, providing routing, switching, and policy-based traffic management. It uses hardware-based forwarding engines to deliver low-latency performance. The AVB capability ensures synchronized audio and video streaming over Ethernet, making it ideal for multimedia environments.
Applications
Ideal for enterprise edge deployments, campus networks, educational institutions, and multimedia studios. Supports VoIP, wireless access points, IP cameras, and AVB-enabled audio/video equipment.
Specifications
| Attribute | Value |
|---|---|
| Ports | 12 x 10/100/1000BASE-T, 4 x 1GbE SFP (upgradable to 10GbE) |
| Switching Capacity | 104 Gbps |
| Forwarding Rate | 77.4 Mpps |
| Power Consumption | 15W (min) - 32W (max) |
| Dimensions | 1RU, 12.01" W x 10.28" D x 1.73" H |
| Weight | 5.82 lb (2.64 kg) |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Stacking | SummitStack-V (up to 8 units) |
| AVB Support | Yes (on select ports) |
Advantages
- Software-upgradable 10GbE ports reduce hardware refresh costs
- Low-latency AVB support for professional audio/video applications
- Robust security with ACLs, role-based policies, and threat detection
- Energy-efficient design with EEE and variable-speed fans
- Compatible with ExtremeCloud™ for centralized cloud management
Service & Support
All Extreme Networks switches come with a limited lifetime warranty. We offer 24/7 technical support, zero-touch provisioning, and global logistics support. Same-day shipping available for in-stock items.
FAQ
Q: Can the SFP ports be upgraded to 10GbE?
A: Yes, with a software license (Dual or Quad 10GbE upgrade).
Q: Does this switch support stacking?
A: Yes, via SummitStack-V using two of the uplink ports.
Q: Is AVB supported on all ports?
A: AVB is supported on a limited number of ports per switch. Refer to the datasheet for details.
Q: Is PoE supported?
A: This model (12t) does not support PoE. PoE models are available (e.g., X440-G2-12p-10GE4).
Precautions
- Do not use extended temperature models for stacking or 10GbE upgrades.
- Ensure proper ventilation and airflow to prevent overheating.
- Use only certified SFP/SFP+ modules for compatibility and warranty.
- Follow local electrical and EMC regulations during installation.
