Extreme Network Switch X440 Series Switch X440-G2-24p-10ge4 Extreme Xos
Product Details:
| Brand Name: | Extreme |
| Model Number: | X440-G2-24P-10GE4 |
| Document: | x440-g2-data-sheet.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Delivery Time: | Based on inventory |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Model NO.: | X440-G2-24p-10GE4 | Transmission Rate: | 10/100/1000Mbps |
|---|---|---|---|
| Ports: | 24 | Operating System: | Extreme Xos |
| L3: | WLAN/STP/Lldp/Lacp | Poe: | 380W |
| Transport Package: | Carton | Specification: | 305× 440 × 43.94mm |
| Highlight: | Extreme Xos X440-G2-24p-10ge4 Switch,X440-G2-24p-10ge4 Extreme Network Switch |
||
Product Description
ExtremeSwitching X440-G2-24p-10GE4: Power-Full Stackable Switch for Modern Networks
Engineered for demanding edge environments, the Extreme Networks X440-G2-24p-10GE4 is a versatile 24-port Gigabit Ethernet switch that delivers robust Power over Ethernet Plus (PoE+) capabilities, high-speed uplink flexibility, and advanced stackability. This switch is a cornerstone for building scalable, secure, and high-performance network infrastructure, perfect for powering everything from wireless access points to IP surveillance systems.
Core Characteristics
- High-Density PoE+: 24 ports delivering up to 30W per port (IEEE 802.3at) for powering modern devices.
- Flexible Uplinks: 4 built-in 1GbE SFP combo ports and 4 additional SFP+ ports that can be licensed to 10GbE for high-speed aggregation.
- Unified Stacking: SummitStack-V technology allows for effortless stacking of up to 8 units using standard optics, simplifying management.
- Resilient OS: Powered by the mature ExtremeXOS operating system for reliable Layer 2 and Layer 3 functionality.
- Advanced Management: Ready for cloud-based management via ExtremeCloud™ and supports role-based network policies.
Deployment and Usage
The X440-G2-24p-10GE4 is ideally deployed as an access layer switch in various environments. In education, it powers classrooms full of connected devices and wireless access. In healthcare, it supports VoIP phones and mobile medical carts. For enterprise offices and retail spaces, it provides the backbone for secure wireless coverage, IP cameras, and point-of-sale systems, ensuring both data and power are delivered reliably.
Technical Specifications Table
| Attribute | Specification |
|---|---|
| Total Ports | 24 x 10/100/1000BASE-T RJ-45 (PoE+) |
| SFP/Uplink Ports | 4 x 1G SFP Combo, 4 x 1G/10G SFP+ (upgradable) |
| PoE Budget (Internal PSU) | 380W Total |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 95.2 Mpps |
| Power Consumption (Max) | 500W (with full PoE load) |
| Dimensions (W x D x H) | 17.36" x 10.01" x 1.73" (44.1 x 25.4 x 4.4 cm) |
| Weight | 9.44 lb (4.28 kg) |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
Competitive Advantages
This model stands out from other switches in its class through several key differentiators. Its software-based 10GbE upgrade path protects investments by eliminating the need for a hardware swap. The support for long-distance stacking (up to 40km) with SummitStack-V provides exceptional deployment flexibility for distributed campuses. Furthermore, integration with the broader Extreme ecosystem, including ExtremeCloud™ and ExtremeManagement Center, offers a single-pane-of-glass management experience that many competitors cannot match, reducing operational complexity.
Service, Support, and Warranty
This switch is backed by Extreme Networks' limited lifetime warranty. Our company complements this with value-added services including competitive bulk pricing, rapid logistics to ensure timely delivery, and expert pre-sales technical consultation. Our team provides ongoing support to assist with integration and configuration, ensuring optimal performance from your network hardware.
Frequently Asked Questions
Q: How do I upgrade the SFP+ ports to 10GbE?
A: A software license (e.g., Part #16541 for a quad upgrade) is required to activate 10GbE functionality on the four SFP+ ports.
Q: Can this switch stack with older Extreme models?
A: SummitStack-V allows it to stack with other X440-G2, X450-G2, X460-G2, X670-G2, and X770 switches, provided they all run the same version of ExtremeXOS.
Q: What is the maximum power provided per PoE port?
A: It supports the IEEE 802.3at (PoE+) standard, delivering up to 30W per port.
Q: Is redundant power an option?
A: Yes, an external Redundant Power Supply (RPS) like the RPS-500p or EPS-C2 can be added for power redundancy.
Q: Does it support audio and video streaming applications?
A: Yes, it supports IEEE 802.1 Audio Video Bridging (AVB) for prioritized, low-latency media traffic.
Critical Precautions
- Ensure adequate cooling and do not exceed the specified operating temperature range.
- When using 10GBASE-T SFP+ transceivers, populate every other port and leave adjacent ports unused for proper thermal management.
- Verify the total power draw of all connected PoE devices does not exceed the total 380W budget.
- Extended temperature models (0°C to 60°C) do not support 10GbE upgrades or stacking.
- Always use certified and compatible optical transceivers and cables for guaranteed performance.
