Extreme Network Switch X440 Series Switch 16532 440-G2-24t-10GE4 Extreme Xos
Product Details:
| Brand Name: | Extreme |
| Model Number: | 440-G2-24t-10GE4 |
| Document: | x440-g2-data-sheet.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Delivery Time: | Based on inventory |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Model NO.: | 440-G2-24t-10GE4 | Transmission Rate: | 10/100/1000Mbps |
|---|---|---|---|
| Ports: | 24 | Operating System: | Extreme Xos |
| L3: | WLAN/STP/Lldp/Lacp | Poe: | 380W |
| Transport Package: | Carton | Specification: | 305× 440 × 43.94mm |
| Highlight: | 16532 Switch,Extreme Xos Switch,440-G2-24t-10GE4 Switch |
||
Product Description
ExtremeSwitching X440-G2-24t-10GE4: Scalable, High-Performance Edge Switch
1. Product Overview
The ExtremeSwitching X440-G2-24t-10GE4 is a high-performance, cost-effective edge switch designed for modern enterprise networks. Powered by the resilient ExtremeXOS operating system, it delivers reliable Layer 2 and Layer 3 switching, advanced security, and flexible stacking capabilities. Ideal for campus and branch deployments, this switch supports PoE, cloud management, and high-density Gigabit Ethernet connectivity.
2. Key Features
- 24 x 10/100/1000BASE-T ports + 4 combo SFP ports
- 4 x 1GbE SFP uplink ports (upgradable to 10GbE via license)
- Support for ExtremeCloud™ management
- IEEE 802.3at PoE-Plus support
- SummitStack-V stacking (up to 8 units)
- Role-based policy enforcement
- Energy Efficient Ethernet (EEE)
- Redundant power supply (RPS) support
3. Supported Technologies & Standards
- IEEE 802.3ab, 802.3z, 802.3ae, 802.3at, 802.3az
- IPv4/IPv6 routing
- Audio Video Bridging (AVB)
- Bidirectional ACLs, QoS, bandwidth policing
- ExtremeXOS with SDN (OpenFlow) support
4. How It Works
The X440-G2-24t-10GE4 operates as a fully non-blocking switch, processing traffic at wire speed with less than 4 microseconds of latency. It uses role-based policies to enforce security and access controls, and supports SummitStack-V for virtual stacking over standard 10GbE optics. PoE capabilities allow it to power devices like IP phones, cameras, and wireless access points directly from the switch.
5. Applications
- Enterprise campus networks
- Education and healthcare facilities
- Retail and hospitality environments
- IP surveillance and VoIP deployments
- Wireless access point aggregation
6. Technical Specifications
| Specification | Value |
|---|---|
| Ports | 24 x 10/100/1000BASE-T, 4 x SFP Combo, 4 x SFP/Uplink |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 95.2 Mpps |
| PoE Support | IEEE 802.3af/at |
| Stacking | SummitStack-V (up to 8 units) |
| Power Consumption | 26W (min) - 40W (max) |
| Dimensions (HxWxD) | 1.73" x 17.36" x 10.01" |
| Weight | 8.07 lb (3.66 kg) |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
7. Advantages & Selling Points
- Software-upgradable 10GbE uplinks reduce future upgrade costs
- Cloud-manageable via ExtremeCloud for centralized control
- High PoE budget for powering multiple devices
- Low latency and high throughput for real-time applications
- Interoperable with other Extreme switches in mixed stacks
8. Service & Support
We offer lifetime limited warranty, 24/7 technical support, and fast shipping from our extensive inventory. Our team provides pre-sales consultation and post-sales integration services to ensure smooth deployment.
9. Frequently Asked Questions
Q: Can the SFP ports be upgraded to 10GbE?
A: Yes, with a software license, the four SFP uplink ports can be upgraded to 10GbE.
Q: Does this switch support stacking?
A: Yes, it supports SummitStack-V stacking with up to 8 switches using standard 10GbE optics.
Q: Is PoE supported on all ports?
A: Yes, all 24 RJ-45 ports support IEEE 802.3at PoE-Plus.
Q: What is the maximum power consumption?
A: Maximum power consumption is 40W without PoE load.
10. Precautions
- Do not use extended temperature models for 10GbE upgrades.
- Ensure proper ventilation and airflow side-to-side.
- Use compatible SFP/SFP+ modules for optimal performance.
- Follow EMC and safety standards during installation.
