H3c S5120V3-52S-LI Network Switch 52port Management Access Switch
Product Details:
| Brand Name: | H3C |
| Model Number: | S5120V3-52S-LI |
| Document: | H3C S5120V3-LI.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 378 |
|
Detail Information |
|||
| Model NO.: | S5120V3-52S-LI | Transmission Rate: | 10g SFP+ |
|---|---|---|---|
| Ports: | ≧48 | Exchange Capacity: | 336gbps/3.36tbps |
| Packet Forwarding Rate: | 126/144mpps | Transport Package: | Carton |
| Specification: | 440× 260× 43.6mm | Trademark: | H3C |
| Origin: | China | ||
Product Description
The H3C S5120V3-52S-LI is a high-performance Layer 2 managed switch designed for enterprise and campus network access layers. It features 48x 10/100/1000BASE-T ports and 4x 1G/10G SFP+ uplink ports, providing flexible connectivity and high bandwidth. With support for advanced features like IRF stacking, comprehensive security controls, IPv6, and energy-efficient operation, this H3C switch offers reliable and scalable networking for modern business environments.
- 48x Gigabit Ethernet ports + 4x 1G/10G SFP+ uplinks
- IRF (Intelligent Resilient Framework) stacking technology
- IPv4/IPv6 dual-stack support
- Advanced security: 802.1X, MAC authentication, ACLs, ARP protection
- Energy-efficient design with auto power-down and EEE
- Comprehensive QoS and multicast support
The S5120V3-52S-LI supports key networking protocols including STP/RSTP/MSTP, LACP, RIP, OSPF, and static routing. It also features H3C’s IRF technology for virtual stacking, SmartMC for centralized management, and robust Layer 2–4 ACLs for traffic control.
The H3C S5120V3-52S-LI operates as an access layer switch, connecting end-user devices and aggregating traffic to core switches via high-speed uplinks. It uses hardware-based forwarding and policy-based traffic management to ensure low latency and high reliability. IRF allows multiple units to be stacked and managed as one logical device.
- High-density office and campus access networks
- Data center edge connectivity
- IP surveillance and VoIP systems
- Wireless LAN aggregation
| Model | Port Configuration | Switching Capacity | Forwarding Rate | Power Consumption | Dimensions (W*D*H mm) |
|---|---|---|---|---|---|
| S5120V3-52S-LI | 48x GE + 4x SFP+ | 336 Gbps | 126 Mpps | 41W | 440*230*43.6 |
| S5120V3-52P-LI | 48x GE + 4x SFP | 336 Gbps | 126 Mpps | 39W | 440*230*43.6 |
- High port density with 10G-ready uplinks
- Flexible stacking with IRF2 for simplified management
- Advanced security and compliance features
- Energy-efficient operation with green Ethernet technology
- Robust QoS for voice and video traffic
We offer worldwide shipping, 24/7 technical support, and manufacturer warranty. Custom configuration and integration services are available. All H3C products are sourced directly and tested for quality assurance.
Q: Does the S5120V3-52S-LI support PoE?A: No, this model does not support PoE. For PoE capabilities, consider the S5120V3-52P-PWR-LI.
Q: Can I stack this switch with other H3C models?A: Yes, it supports IRF stacking with up to 9 compatible H3C switches.
Q: Is IPv6 supported?A: Yes, full IPv6 routing and management is supported.
- Ensure adequate ventilation and operating temperature (0°C to 45°C).
- Use compatible SFP/SFP+ modules for fiber uplinks.
- Verify power requirements and grounding for stable operation.
- Update firmware to the latest version for security and feature enhancements.
