Nvidia Q3200-Ra Quantum-3 Based Two-Adjoining Xdr Infiniband Switches with Vlan Support 2u 36 Xdr Ports 18 Osfp Cages
Product Details:
| Brand Name: | Mellanox |
| Model Number: | Q3200-RA(920-9B34F-00RX-FS0) |
| Document: | q3200-ra-q3400-ra-xdr-800gb...al.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Model NO.: | Q3200-RA(920-9B34F-00RX-FS0) | Transmission Rate: | 800g |
|---|---|---|---|
| Ports: | 36 | Function: | Lacp, Stackable, Vlan Support |
| Technology: | Infiniband | Max Speed: | Xdr |
| Transport Package: | Packing | Specification: | 43.6*433.2*590.6 Mm |
| Trademark: | Mellanox | ||
Product Description
NVIDIA Quantum-3 Q3200-RA XDR 800Gb/s InfiniBand Switch System
Product Overview
The NVIDIA Q3200-RA is a high-performance, 2U, air-cooled InfiniBand switch system designed for modern AI and HPC infrastructures. Based on the NVIDIA Quantum-3 ASIC, it delivers exceptional throughput, low latency, and scalable connectivity. This network switch supports up to 72 ports of 800Gb/s InfiniBand over 36 OSFP cages, making it ideal for high-density data centers and large-scale computational environments.
Key Features
- 72 ports of 800Gb/s InfiniBand over 36 OSFP cages
- 57.6 Tb/s maximum throughput
- NVIDIA Quantum-3 switch ASIC technology
- Dedicated in-band management port for NVIDIA UFM®
- Redundant, hot-swappable power supplies and fans
- Support for Fat Tree, Dragonfly+, and Torus topologies
Core Technology
The Q3200-RA leverages NVIDIA's Quantum-3 ASIC and XDR (eXtended Data Rate) InfiniBand technology, enabling 800Gb/s per port with 64b/66b encoding. It supports advanced features like NVIDIA SHARP™ (Scalable Hierarchical Aggregation and Reduction Protocol), adaptive routing, and performance isolation.
How It Works
The switch operates by routing high-speed data packets between connected nodes with minimal latency. Each OSFP cage supports breakout configurations, allowing flexible port splitting for mixed-speed environments (40G to 800G). The system uses a non-blocking architecture to ensure full bandwidth across all ports simultaneously.
Applications
- High-Performance Computing (HPC) clusters
- Artificial Intelligence and Machine Learning training networks
- Large-scale data analytics and cloud infrastructure
- Scientific research and simulation environments
Specifications
| Feature | Specification |
|---|---|
| Model | Q3200-RA |
| Ports | 72 x 800Gb/s over 36 OSFP cages |
| Throughput | 57.6 Tb/s |
| Power Supply | 4 x 2000W (redundant) |
| Dimensions | 2U, 88mm H x 438mm W x 680mm D |
| Weight | 23kg (with 2 PSUs) |
| Airflow | C2P (Connector to Power) |
Advantages
- Higher radix and lower latency compared to previous generations
- Enhanced energy efficiency with optimized cooling design
- Flexible topology support for diverse network architectures
- Robust management via NVIDIA UFM® and NVOS
Service & Support
We offer comprehensive technical support, on-site service options, and a standard warranty. Customized integration and configuration services are available. Contact our team for lead times and regional service coverage.
FAQ
Q: What is the maximum cable length supported?
A: Depending on the transceiver and cable type, supported lengths range from 50m to 500m.
Q: Can the Q3200-RA be used in existing HDR or NDR networks?
A: Yes, it supports backward compatibility and hybrid network configurations.
Q: Is the network switch compatible with standard 19-inch racks?
A: Yes, it includes tool-less rail kits for easy installation.
Precautions
- Ensure proper airflow and ambient temperature (0°–35°C)
- Use only NVIDIA-certified cables and transceivers
- Follow ESD and electrical safety protocols during installation
- Do not stack chassis or obstruct ventilation openings
