Mellanox cable MFP7E10-N015 MPO-12/APC to MPO-12/APC Multimode Optical Fiber Cable
Product Details:
| Brand Name: | Mellanox |
| Model Number: | MFP7E10-N015(980-9I57Y-000015) |
| Document: | MFP7E10-Nxxx.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Product Model: | MFP7E10-N015 | Cable Type: | Multimode OM4 |
|---|---|---|---|
| Length: | 15 Meters | Connector Type: | MPO-12/APC (Female To Female) |
| Maximum Data Rate: | 400G | Insertion Loss: | ≤ 0.35 + 0.0004*L DB |
| Highlight: | Passive dac sfp cable,5M dac sfp cable,Copper 5m dac cable |
||
Product Description
NVIDIA MFP7E10-N015 MPO-12/APC to MPO-12/APC Multimode Optical Fiber Cable
Product Overview
The NVIDIA MFP7E10-N015 is a high-performance passive optical fiber cable specifically engineered for 400G InfiniBand and Ethernet applications in modern data centers. This 15-meter multimode optical fiber cable features precision MPO-12/APC connectors on both ends, ensuring superior signal integrity with minimal insertion loss. Designed for reliability in demanding environments, this passive fiber cable facilitates high-speed connections between switches, adapters, and data processing units, making it an ideal solution for data-intensive computing applications.
Key Characteristics
- Dual MPO-12/APC female connectors with 8-degree angled polish for optimal reflection reduction
- Comprehensive support for InfiniBand NDR, Ethernet, and NVLink communication protocols
- 50/125 µm OM4 multimode fiber construction with aqua LSZH protective jacket
- Type-B crossover fiber alignment enabling direct transceiver-to-transceiver connectivity
- Compliance with IEC 61754-7, ANSI/TIA/EIA 604-5, and Telcordia GR-1435 standards
Technical Specifications
| Specification | Value |
|---|---|
| Product Model | MFP7E10-N015 |
| Cable Type | Multimode OM4 |
| Length | 15 meters |
| Connector Type | MPO-12/APC (Female to Female) |
| Maximum Data Rate | 400G |
| Insertion Loss | ≤ 0.35 + 0.0004*L dB |
| Return Loss | ≥ 35 dB |
| Operating Temperature | 0°C to 70°C |
| Fiber Count | 8 fibers (4Tx/4Rx) |
| Minimum Bend Radius | 30 mm |
| Cable Diameter | 3.0 ± 0.2 mm |
Technical Operation
This advanced optical fiber cable utilizes a Type-B fiber crossover configuration, where transmission channels from the source module are precisely aligned with reception channels on the destination module. This sophisticated optical fiber cable design eliminates the need for intermediary equipment in direct transceiver connections. The innovative APC polishing technology ensures exceptional signal integrity through significant reduction of reflected light interference, making this passive fiber cable ideal for high-performance computing environments.
Implementation Scenarios
- High-density data center spine-leaf architecture interconnections
- Supercomputing and high-performance computing cluster infrastructures
- Artificial intelligence and machine learning deployment environments
- Enterprise-scale cloud storage and computational networks
- ConnectX-7 and BlueField-3 adapter integration systems
- High-frequency trading network infrastructure
Competitive Advantages
- Exceptional signal fidelity through precision APC polished connectors
- Broad interoperability with NVIDIA transceivers and switching platforms
- Flexible and robust LSZH jacket ensuring secure deployment operations
- Factory-terminated and pre-validated for immediate deployment reliability
- Superior optical performance characteristics exceeding industry standards
- Reduced power consumption compared to active optical cables
Service & Support Framework
We provide comprehensive technical support services available 24/7, global logistics capabilities, and complete warranty coverage on all product offerings. Our specialized team delivers pre-sales architectural consultation and post-sales technical troubleshooting to ensure seamless system integration and operational excellence for this optical fiber cable and related networking products.
Frequently Asked Questions
Q: What is the maximum distance supported by this passive fiber cable?
A: The MFP7E10-N015 supports distances up to 50 meters using OM4 multimode fiber, depending on specific link configuration and transceiver compatibility.
Q: Can this optical fiber cable be used with non-NVIDIA equipment?
A: Yes, this passive fiber cable is compatible with any equipment supporting MPO-12/APC connectors and multimode fiber specifications, regardless of manufacturer.
Q: What safety certifications does this optical fiber cable hold?
A: This product is certified with CB, cTUVus, CE safety standards and complies with FCC, ICES, RCM, VCCI EMC requirements.
Installation Considerations
- APC and UPC connectors are optically incompatible - do not intermix
- Implement proper connector cleaning procedures before installation
- Maintain minimum bend radius of 30 mm during installation
- Store in controlled environments avoiding dust and moisture contamination
- Observe standard ESD precautions during handling and installation
- Use only approved optical connector cleaning tools
