Mellanox cable MFP7E10-N005 MPO-12/APC to MPO-12/APC Multimode Optical Fiber Cable
Product Details:
| Brand Name: | Mellanox |
| Model Number: | MFP7E10-N005 (980-9I73V-000005) |
| Document: | MFP7E10-Nxxx.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Part Number: | MFP7E10-N005 (980-9I73V-000005) | Cable Type: | Multimode Fiber Cable |
|---|---|---|---|
| Fiber Type: | OM4, 50/125 µm | Length: | 5 M |
| Connectors: | MPO-12/APC (Female) | Data Rate: | Up To 400 Gbps |
| Highlight: | QSFP+ 40gb dac cable,Mellanox 40gb dac cable,20M qsfp dac cable |
||
Product Description
NVIDIA MFP7E10-N005 MPO-12/APC to MPO-12/APC Multimode Optical Fiber Cable
Product Overview
The NVIDIA MFP7E10-N005 is a high-performance passive optical fiber cable designed for 400G InfiniBand and Ethernet applications. This 5-meter multimode cable features MPO-12/APC connectors on both ends, ensuring low insertion loss and high reliability in data center environments. It supports high-speed interconnections between switches, adapters, and DPUs, making it ideal for modern data-intensive workloads.
Key Features
- MPO-12/APC female connectors with angled polish for reduced back reflection
- Supports InfiniBand NDR, Ethernet, and NVLink protocols
- 50/125 µm OM4 multimode fiber with aqua LSZH jacket
- Type-B crossover fiber mapping for direct transceiver-to-transceiver connection
- Compliant with IEC 61754-7 and Telcordia GR-1435 standards
Technology & Standards
The MFP7E10 optical fiber cable utilizes MPO-12/APC connectors with an 8-degree polish to minimize optical back reflection. It complies with international standards including IEC 61754-7, ANSI/TIA/EIA 604-5, and is rated for OFNR/LSZH environments. The cable supports InfiniBand NDR, Ethernet 400G, and NVLink protocols.
How It Works
The cable uses a Type-B fiber crossover configuration. Transmit lanes from one end are connected to receive lanes on the opposite end, enabling direct connection between two transceivers without additional equipment. The APC polish ensures signal integrity by reducing reflected light.
Applications
- Data center spine-leaf switch interconnections
- High-performance computing clusters
- AI and machine learning infrastructure
- Cloud and enterprise storage networks
- ConnectX-7 and BlueField-3 adapter connections
Specifications
| Parameter | Value |
|---|---|
| Product Model | MFP7E10-N005 |
| Cable Type | Multimode OM4 |
| Length | 5 meters |
| Connectors | MPO-12/APC (Female to Female) |
| Data Rate | Up to 400G |
| Insertion Loss | ≤ 0.35 + 0.0004*L dB |
| Return Loss | ≥ 35 dB |
| Operating Temperature | 0°C to 70°C |
Advantages
- Superior signal integrity with APC polished connectors
- Wide compatibility with NVIDIA transceivers and switches
- Flexible and durable LSZH jacket for safe deployment
- Pre-terminated and tested for out-of-the-box reliability
Service & Support
We offer 24/7 technical support, worldwide shipping, and a full warranty on all products. Our team provides pre-sales consultation and post-sales troubleshooting to ensure seamless integration.
FAQ
Q: Can I use this cable with non-NVIDIA equipment?
A: Yes, provided the equipment supports MPO-12/APC connectors and multimode fiber.
Q: What is the maximum supported distance?
A: Up to 50 meters with OM4 fiber, depending on link configuration.
Q: Is this fiber cable compatible with UPC connectors?
A: No, APC and UPC connectors are not interoperable due to different polish types.
Precautions
- Do not mix APC with UPC connectors
- Always clean connectors before installation
- Avoid bending below 30 mm radius
- Store in dry, dust-free environment
