Mellanox Network Switch MSN3700-CS2F 100GbE 1U 2 Power Supplies (AC)

Product Details:

Brand Name: Mellanox
Model Number: MSN3700-CS2F
Document: sn3000-series.pdf

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: Negotiate
Packaging Details: outer box
Payment Terms: T/T
Supply Ability: Supply by project/batch
Get Best Price Contact Now

Detail Information

Ports:: 32 QSFP28 Ports Transmission Rate: 100GbE
Function: LACP, Stackable, VLAN Support Communication Mode: Full-Duplex & Half-Duplex
Switch Capacity: 100GbE Technology: Ethernet
System Weight: 11.1kg System Dimensions: 44mm X 428mm X 559mm
Rack Mount: 1U Rack Mount Condition: New
Highlight:

FDR Mellanox Network Switch

,

100GbE Mellanox Network Switch

,

100GbE mellanox fdr switch

Product Description

NVIDIA Spectrum SN3000 Series MSN3700-CS2F 100GbE Open Ethernet Switch

1. Product Overview

The NVIDIA Spectrum SN3000 Series MSN3700-CS2F is a high-performance, 1U open Ethernet switch designed for modern data center leaf and spine deployments. Built on the Spectrum-2 ASIC, it delivers 6.4 Tb/s bidirectional throughput with 32x 100GbE QSFP28 ports. It supports multiple network operating systems including NVIDIA Onyx®, Cumulus Linux®, and ONIE-enabled options, providing flexibility and avoiding vendor lock-in. This network switch is ideal for cloud, enterprise, and high-performance computing environments.

2. Key Characteristics

  • 32 x 100GbE QSFP28 ports, splittable to 128 x 10/25GbE
  • 6.4 Tb/s switching capacity, 4.76 Bpps forwarding rate
  • 42 MB fully shared packet buffer
  • Cut-through latency as low as 425 ns
  • Support for multiple NOS: NVIDIA Onyx, Cumulus Linux, SONIC, ONIE
  • Hardware Root of Trust (HRoT) for secure boot (on -S models)
  • 1+1 redundant hot-swappable power supplies, N+1 fans

3. Core Technologies

The SN 2000 series successor, the SN3000 leverages NVIDIA’s Spectrum-2 ASIC with support for:

  • VXLAN routing and bridging
  • RoCE (RDMA over Converged Ethernet)
  • In-band network telemetry (INT) and NVIDIA WJH®
  • IPv6 Segment Routing
  • 512K flow counters and ACL scale
  • Docker container support for on-switch applications

4. Working Principle

The network switch operates at wire speed using a fully shared packet buffer architecture. It supports cut-through forwarding to minimize latency. The programmable pipeline allows deep packet inspection (up to 512B) and supports advanced tunneling and encapsulation protocols. The switch can be managed via standard CLI, REST APIs, or integrated with NVIDIA Cumulus NetQ for real-time visibility and automation.

5. Applications

  • Data center leaf/spine architectures
  • High-performance computing (HPC) and AI clusters
  • Cloud infrastructure and hyper-converged systems
  • Financial trading and low-latency networks
  • Media and entertainment data fabrics

6. Specifications & Selection

Feature Specification
Model MSN3700-CS2F
Ports 32 x QSFP28 100GbE
Throughput 6.4 Tb/s
Packet Buffer 42 MB
Latency 425 ns
Power Supplies 2 (1+1 redundant), AC
OS Preload NVIDIA Onyx
Airflow Port-to-Cooling (P2C)

7. Advantages & Selling Points

  • Superior performance with low latency and high throughput
  • Flexible port splitting and protocol support
  • Rich telemetry and visibility with WJH technology
  • Open Ethernet ecosystem avoids vendor lock-in
  • Robust security features including secure boot

8. Service & Support

All SN3000 series switches include a 1-year limited hardware warranty with 14-business-day repair turnaround. Optional support services include next-business-day advance replacement, 4-hour technician dispatch, and remote or on-site installation and configuration services. Global technical support is available through NVIDIA’s service network.

9. Frequently Asked Questions

Q: Can the MSN3700-CS2F support 25GbE connections?
A: Yes, each 100GbE port can be split into 4x 25GbE ports using breakout cables.

Q: Is the switch compatible with third-party optics?
A: Yes, it supports standard QSFP28 transceivers and DAC/AOC cables from multiple vendors.

Q: What operating systems are supported?
A: NVIDIA Onyx, Cumulus Linux, SONIC, DENT, and any ONIE-compatible NOS.

Q: Does it support RoCE?
A: Yes, it fully supports RoCE for NVMe-oF and GPU-direct workloads.

10. Precautions

  • Ensure compatible airflow direction (P2C or C2P) matches data center cooling.
  • Use only certified transceivers and cables for optimal performance.
  • Operating temperature: 0°C to 40°C; humidity: 5% to 85% non-condensing.
  • Complies with CE, FCC, RoHS, and other international standards.
