RUCKUS ICX 8200-C08ZP Compact Multigigabit PoE++ Switch
Product Details:
| Brand Name: | Ruckus |
| Model Number: | ICX8200-C08ZP |
| Document: | RUCKUS ICX 8200 Switch Data...et.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Delivery Time: | Based on inventory |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Product Name: | ICX8200-C08ZP | Condition: | Original |
|---|---|---|---|
| Ports: | 8× Multigigabit RJ-45 PoE++, 2× SFP28 | PoE Budget: | 240W |
| Switching Capacity 200 Gbps: | 200 Gbps | Forwarding Rate: | 148 Mpps |
| Highlight: | Zoneflex Dual Ruckus Wireless Access Points,R300 Ruckus Wireless Access Points,901-R300-WW02 |
||
Product Description
RUCKUS ICX 8200-C08ZP Compact Multigigabit PoE++ Switch
1. Product Overview
The RUCKUS ICX 8200-C08ZP is a high-density, compact Multigigabit PoE++ switch designed for next-generation wireless and IoT deployments. It delivers enterprise-class performance, scalability, and power efficiency in a small form factor, making it ideal for space-constrained environments requiring high-speed connectivity and advanced Power over Ethernet capabilities.
2. Key Features
- 8 Multigigabit PoE++ ports (4× 100/1000/2500 Mbps + 4× 1/2.5/5/10 Gbps)
- Up to 90W per port (802.3bt PoE++)
- 2× 1/10/25 GbE SFP28 uplink/stacking ports
- 240W total PoE budget
- Fanless operation for silent deployment
- Stackable with up to 12 units
- Advanced Layer 3 routing (with license)
- USB Type-C console management
3. Core Technologies
The ICX 8200-C08ZP supports IEEE 802.3bt (PoE++), 802.3bz (Multigigabit), 802.1X, VXLAN, OSPF, VRRP, and OpenFlow. It also features Energy Efficient Ethernet (802.3az) and advanced QoS and security protocols.
4. Working Principle
The switch operates as a fully managed Layer 2/3 device, supporting dynamic traffic routing, PoE power management, and stackable architecture. It uses hardware-based forwarding and centralized management via RUCKUS SmartZone, Cloud, or Unleashed platforms.
5. Applications
Ideal for Wi-Fi 6/6E/7 access point deployments, IoT hubs, educational campuses, healthcare networks, and retail environments where high-density PoE and Multigigabit connectivity are required.
6. Specifications
| Specification | Value |
|---|---|
| Model | ICX 8200-C08ZP |
| Ports | 8× Multigigabit RJ-45 PoE++, 2× SFP28 |
| PoE Budget | 240W |
| Switching Capacity | 200 Gbps |
| Forwarding Rate | 148 Mpps |
| Power Supply | Integrated 305W AC |
| Dimensions (H×W×D) | 4.4×27.0×26.0 cm |
| Weight | 3.23 kg |
| Operating Temperature | 0°C to 45°C |
7. Advantages
- Future-proof Multigigabit and PoE++ support for Wi-Fi 6/6E/7 access points
- High-density stacking with up to 12 units and 10km distance
- Fanless design for noise-sensitive environments
- Advanced security features including MACsec and VXLAN
- 3-year remote TAC support and limited lifetime warranty
8. Service & Support
All ICX 8200 switches include 3 years of remote TAC support and a limited lifetime warranty. Next-business-day advanced replacement is available in supported regions.
9. FAQ
Q: What is the maximum PoE power per port?
A: Up to 90W per port (IEEE 802.3bt PoE++).
Q: Is the switch stackable?
A: Yes, it supports stacking with up to 12 ICX 8200 switches.
Q: Does it support Layer 3 routing?
A: Yes, with an optional premium license for OSPF, VRRP, PIM, and more.
10. Precautions
- Use high-temperature C15 power cord for PoE++ models.
- Ensure adequate ventilation for PoE load above 150W.
- Verify compatible optics and cables for SFP28 ports.
- Comply with local electrical and safety regulations.
