MCX653106A-HDAT-SP Mellanox Network Card 200gbe High Speed Smart Safe
Product Details:
| Brand Name: | Mellanox |
| Model Number: | MCX653106A-HDAT-SP |
| Document: | connectx-6-infiniband.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Products Status: | Stock | Application: | Server |
|---|---|---|---|
| Condition: | New And Original | Type: | Wired |
| Max Speed: | Up To 200 Gb/s | Ethernet Connector: | QSFP56 |
| Model: | MCX653106A-HDAT | Name: | MCX653106A-HDAT-SP Mellanox Network Card 200gbe High Speed Smart Safe |
| Highlight: | MCX653106A-HDAT-SP mellanox network card,200gbe Speed mellanox network card,MCX653106A-HDAT-SP mellanox 200gbe nic |
||
Product Description
NVIDIA ConnectX-6 MCX653106A-HDAT 200Gb/s InfiniBand Smart NIC Card
The NVIDIA ConnectX-6 MCX653106A-HDAT is a high-performance dual-port network card supporting 200Gb/s InfiniBand and Ethernet connectivity. Designed for data-intensive environments, this nic card features hardware offloads, in-network computing, and advanced security, making it ideal for HPC, AI, and cloud infrastructures.
Key Features
- Dual-port 200Gb/s InfiniBand/Ethernet connectivity
- Hardware offloads for RDMA, NVMe-oF, and encryption
- In-Network Computing acceleration
- Low latency and high message rate (215M msg/s)
- Block-level AES-XTS encryption with FIPS compliance
Technology
The ConnectX-6 leverages InfiniBand Architecture Specification 1.3, RoCE (RDMA over Converged Ethernet), PCIe Gen 4.0, and hardware-based offloads for networking, storage, and security. It supports SR-IOV, overlay networks (VXLAN, Geneve), and advanced virtualization.
How It Works
The nic card uses remote direct memory access (RDMA) to enable direct data movement between servers and storage, bypassing the CPU. Its in-network computing engines offload collective operations and encryption, reducing host overhead and improving efficiency.
Applications
- High-Performance Computing (HPC) clusters
- AI and machine learning training networks
- Cloud data centers and hyperscale environments
- Storage area networks (NVMe-oF, iSER, SMB Direct)
- Virtualized and NFV infrastructure
Specifications
| Attribute | Value |
|---|---|
| Model | MCX653106A-HDAT |
| Ports | 2 x QSFP56 |
| Max Speed | 200Gb/s per port |
| Host Interface | PCIe Gen 4.0 x16 |
| Protocols | InfiniBand, Ethernet |
| Encryption | AES-XTS 256/512-bit |
| Latency | Sub-microsecond |
| Message Rate | 215M messages/sec |
| Form Factor | Low-profile PCIe |
| Compliance | RoHS, FIPS, ODCC |
Advantages
- Superior throughput and lower latency compared to previous generations
- Hardware offloads reduce CPU utilization and improve scalability
- Enhanced security with inline encryption and FIPS compliance
- Broad support for virtualization and cloud-native environments
- Compatible with x86, ARM, Power, and GPU-based systems
Service & Support
We provide 24/7 technical support, worldwide shipping, and integration services. All products come with a standard manufacturer warranty and lifetime customer service consultation.
FAQ
Q: What systems are compatible with the ConnectX-6 network card?
A: It is compatible with servers supporting PCIe Gen 3.0/4.0 x16 slots and major OS including Linux, Windows, VMware.
Q: Does this nic card support RoCE?
A: Yes, it supports RDMA over Converged Ethernet (RoCE) for low-latency Ethernet networks.
Q: Can I use this card in a virtualized environment?
A: Yes, it supports SR-IOV with up to 1,000 virtual functions per port.
Q: Is encryption supported?
A: Yes, hardware-offloaded AES-XTS encryption is supported for block-level data protection.
Q: What cables are required for 200Gb/s operation?
A: QSFP56 DAC or optical cables compatible with 200G InfiniBand or Ethernet.
Precautions
- Ensure proper cooling and airflow in the server chassis.
- Verify PCIe slot compatibility (x16 required for full bandwidth).
- Use certified cables and transceivers for optimal performance.
- Update to the latest firmware and drivers from NVIDIA.
- Follow ESD safety procedures during installation.
