NVIDIA® ConnectX-5 InfiniBand/Ethernet Network Card - MCX653105A-HDAT

1. Product Overview

The NVIDIA ConnectX-5 VPI adapter card, model MCX653105A-HDAT, is a high-performance dual-port network card supporting both InfiniBand and Ethernet connectivity up to 100Gb/s per port. Designed for data centers, high-performance computing (HPC), and enterprise storage environments, this nic card offers advanced offload capabilities, low latency, and high message rates. It supports PCIe Gen4 and features hardware-based acceleration for NVMe over Fabrics, RDMA, and virtualization technologies.

2. Key Characteristics

• Dual-port 100Gb/s InfiniBand or Ethernet connectivity
• PCI Express 4.0 x16 host interface
• Hardware offload for RDMA, NVMe over Fabrics, and TCP/IP
• Support for Multi-Host and Socket Direct technologies
• Low-profile form factor with tail bracket design
• RoHS compliant and energy-efficient operation

3. Core Technologies

The ConnectX-5 leverages cutting-edge technologies including RDMA over Converged Ethernet (RoCE), NVMe over Fabrics offload, and hardware-based virtualization with SR-IOV. It complies with IEEE 802.3 standards for Ethernet and IBTA 1.3 for InfiniBand. The adapter also supports advanced features like adaptive routing, dynamic connected transport (DCT), and MPI tag matching offload.

4. Working Principle

The nic card operates by offloading network processing tasks from the CPU to the adapter’s dedicated hardware. Using RDMA, it enables direct memory access between systems without CPU involvement, reducing latency and improving throughput. The embedded PCIe switch allows efficient I/O consolidation, while hardware-based encryption and tunneling offloads enhance security and performance.

5. Applications

• High-Performance Computing (HPC) clusters
• Cloud and hyperscale data centers
• Enterprise storage and NVMe over Fabrics deployments
• Virtualized environments and software-defined networking (SDN)
• AI and machine learning infrastructure

6. Specifications

7. Advantages

• Industry-leading throughput and lowest latency
• Hardware offload reduces CPU utilization
• Enhanced scalability for compute and storage networks
• Superior reliability with adaptive routing and congestion control
• Future-proof with PCIe Gen4 and multi-host support

8. Service & Support

We provide 24/7 customer consultation and technical support. All products come with a standard warranty. We ensure accurate delivery and offer flexible supply options with large inventory availability. Our professional sales and technical team is ready to assist with integration and deployment.

9. Frequently Asked Questions

Q: What is the difference between ConnectX-5 and ConnectX-6?
A: The ConnectX-6 offers higher port speeds (up to 200Gb/s) and enhanced security features compared to the ConnectX-5.

Q: Is this network card compatible with my existing switch?
A: Yes, the ConnectX-5 supports interoperability with InfiniBand and Ethernet switches up to 100Gb/s.

Q: Does it support virtualization?
A: Yes, it supports SR-IOV with up to 512 virtual functions per port.

10. Precautions

• Ensure proper cooling and airflow in the server chassis.
• Use compatible cables and transceivers for optimal performance.
• Verify driver and firmware compatibility with your OS.
• Follow ESD safety procedures during installation.
