100GbE 2U Open Mellanox Network Switch MSN4600-CS2FC With Cumulus Linux

100GbE 2U Open Mellanox Network Switch MSN4600-CS2FC With Cumulus Linux

100GbE 2U Mellanox Network Switch

Cumulus Linux Mellanox Network Switch


Brand Name:


Model Number:



Request A Quote
Product Details
64 QSFP28
Transmission Rate:
1/10/25/40/50/100GbE Per Port
LACP, Stackable, VLAN Support
Communication Mode:
Full-Duplex & Half-Duplex
Switch Capacity:
1/10/25/40/50/100GbE Per Port
System Weight:
System Dimensions:
88mm (H) X 428mm (W) X 566.4mm (D)
Rack Mount:
1U Rack Mount
Product Description

MSN4600-CS2FC Spectrum-3 Based 100GbE 2U Open Ethernet Switch with Cumulus Linux 64 QSFP28 Ports 2 Power Supplies (AC) x86 CPU Standard Depth P2C Airflow Rail Kit

SN4600C Series Switches

The SN4600C is a 64-port 100GbE network switch system that is ideal for spine/super-spine applications. With a landmark 8.4Bpps processing capacity and 12.8Tb/s throughput in a dense 2U form factor, SN4600C offers diverse connectivity in combinations of 10/25/40/50/100 GbE. The SN4600C is well-suited to answer the challenging needs of large virtualized data centers and cloud environments.


  • NVIDIA What Just Happened (WJH) telemetry dramatically reduces mean time to issue resolution by providing answers to: When, What, Who, Where and Why
  • Hardware-accelerated histograms track and summarize queue depths at submicrosecond granularity
  • Inband Network Telemetry (INT)-ready hardware
  • Streaming Telemetry
  • 512K on-chip flow counters


  • Fully shared packet buffer provides a fair, predictable and high bandwidth data path
  • Consistent and low cut-through latency
  • Intelligent hardware-accelerated data movement, congestion management & load balancing for RoCE & Machine learning applications that leverage NVIDIA GPUDirect
  • Best-in-class VXLAN scale-10X more tunnels and tunnel endpoints
  • 512K shared forwarding entries flexibly shared across ACL, LPM routes, host routes, MAC, ECMP and tunnel applications
  • Up to 1M IPv4 route entries


  • Comprehensive Layer-2, Layer-3 and RoCE
  • Advanced network virtualization with high performance single pass VXLAN routing and IPv6 segment routing
  • Cloud Scale NAT - 100K+ sessions
  • Programmable pipeline that can programmatically parse, process and edit packets
  • Deep Packet Inspection - 512B deep
Packet buffer architecture has a major impact on overall switch performance. The Spectrum-3 packet buffer is monolithic and fully shared across all ports, supporting cut-through line rate traffic from all ports, without compromising scale or features. With its fast packet buffer, Spectrum-3 is able to provide a high-performance fair and bottleneck-free data path for mission-critical applications.
Feature   Value

Size: 3.46’’ x 16.85’’ x 22.3’’
88mm (H) x 428mm (W) x 566.4mm (D)
Mounting: 19” rack mount
Weight: 14.64kg
Speed: SN4600 - 1/10/25/50/100/200GbE per port

SN4600C - 1/10/25/40/50/100GbE per port

Connector cage: 64 QSFP28

Temperature: Operational: 0° to 40°C
Non-Operational: -40° to 70°C
Humidity: Operational: 10% - 85% non-condensing
Non-Operational: 10% - 90% non-condensing
Altitude: 3050m
Noise level: 67.6dBA
Regulatory Safety/ EMC: CB, cTUVus, CE, CU, S_Mark, FCC, VCCI, ICES, RCM, BSMI, KCC, CCC
RoHS: RoHS compliant
Power Input Voltage:

1x/2x, 15A/100 Vac, 15A/110Vac, 12A/120Vac, 10A/200-240Vac,

1x/2x, 10A/100-127Vac, 50/60Hz, 6A/200-240Vac,

Global Power Consumption:

Typical power with passive cables (ATIS): 600W

Typical power with passive cables (ATIS): 466W

Main Devices

CPU: Intel x86 2.20GHz Quad Core
PCIe: 4x Gen 3.0
Switch: NVIDIA Spectrum®-3
Memory: SN4600 - 16GB RAM, 60GB SSD
SN4600C - 8GB RAM, 30GB SSD
Throughput SN4600 - 25.6Tb/s
SN4600C - 12.8Tb/s
