RJ45 48x Extreme X460 Switch PoE+ Console Port 10GE4 Base 48 Ports

Product Details:

Brand Name: Extreme
Model Number: 16706（X460-G2-48x-10GE4-Base）

Payment & Shipping Terms:

Minimum Order Quantity: 1PCS
Price: negotiable
Packaging Details: carton
Delivery Time: 7-10days
Payment Terms: Western Union, MoneyGram, T/T,XT
Supply Ability: 10000pcs/month
Get Best Price Contact Now

Detail Information
Condition: Original Warranty Time: One Year
Lead Time: According To Stock Way: Stackable
Ports: 48 Forwarding Rate: 250 Mpps
Switching Capacity: 336 Gbps Weight: 14.1 Lb (6.4 Kg)
Highlight:

RJ45 extreme x460 switch

,

PoE+ extreme x460 switch

,

PoE+ extreme switch x460

Product Description

ExtremeSwitching™ X460-G2 Series

16706(X460-G2-48x-10GE4-Base)Scalable Fixed-Form Switches for Advanced Edge Access and Aggregation

The ExtremeSwitching 16706(X460-G2-48x-10GE4-Base)seriesis based on Extreme Networks ExtremeXOS®, a highly-resilient OS that provides continuous uptime, managea bility and operational efficiency. Each switch offers the same high-performance, non-blocking hard ware technology. The 16706(X460-G2-48x-10GE4-Base) series switches provide high-performance routing and switching, flexible stacking, PoE+ support and comprehensive security, while extending the benefits of ExtremeXOS to edge and aggregation deployments. The 16706(X460-G2-48x-10GE4-Base)Series easy-to-use, yet powerful, management options include ExtremeCloud IQ and Extreme Management Center for either cloud-based or on-premise oversight and configuration. The 16706(X460-G2-48x-10GE4-Base) also supports rolebased policies and Fabric Attach for secure, automated access to specific network resources and applications.

16706(X460-G2-48x-10GE4-Base) Power over Ethernet (PoE)

Switches support IEEE 802.3at PoE+ and IEEE 802.3af PoE to enable connection of standards compliant PoE devices. Power over Ethernet allows connectionof Ethernet-powered devices, such as wireless access points, Voice over IP phones, and security cameras. The X460-G2 supports full PoE+ 30W power across all 24 or 48 ports using its internal power supplies.

16706(X460-G2-48x-10GE4-Base) Time-Sensitive Streaming

The X460-G2 supports both IEEE 1588 Precision Time Protocol (PTP)* and IEEE 802.1 Audio Video Bridging (AVB) to enable real-time transmission over Ethernet. PTP allows connected devices to be synchronized down to microsecond so f accuracy over Ethernet. While AVB delivers the qualify of service required for high-quality, time-sensitive audio/video multimedia streams.

16706(X460-G2-48x-10GE4-Base) Specifications

  • Network Ports : 48x 1 Gigabit Ethernet RJ-45

  • Uplink Ports : 4x 10 Gigabit Ethernet SFP+

  • Management Ports : 1x Serial (console port RJ-45), 1 x 10/100BASE-T out-of-band management, 1x USB port for external USB flash.

  • Module Slots and Options : 1x VIM Card Module Slot (Ordered Separately) Options are - Summit X460-G2 VIM-2q, Summit X460-G2 VIM-2x, Summit X460-G2 VIM-2t, Summit X460-G2 VIM-2ss.

  • Fan Modules AirFlow Direction : 1x Unpopulated Fan Module Slot. Options are - Summit X460-G2 fan module FB, Summit X460-G2 fan module BF.

  • Power Supplies Included : 2x Unpopulated Power Supply Unit slots. Options are - 10951 Summit 715W AC PSU FB, 10952 Summit 715W AC PSU BF, Summit 300W AC PSU XT, Summit 300W AC PSU BF, Summit 300W +24V/-48V DC PSU, Summit 300W DC PSU BF.

  • Switching Capacity : 336 Gbps

  • Forwarding Rate : 250 Mpps

  • MAC Address Table Size : 98,000

  • Rack Mounts : Included (1-RU)

  • Model Number : 16702

  • Part Number : 16702, X460-G2-48t-10GE4

  • Condition : Seller refurbished

16706(X460-G2-48x-10GE4-Base) Physical (cont.)

Switch Model Weight Physical Dimension
X460-G2-48t-10GE4 13.3 lb (6.03 kg)

Height: 1 RU / 1.73 inches (4.4 cm)

Width: 17.4 inches (44.1 cm)

Depth: 16.94 inches (43.03 cm)
X460-G2-48x-10GE4 14.1 lb (6.4 kg)

Height: 1 RU / 1.73 inches (4.4 cm)

Width: 17.4 inches (44.1 cm)

Depth: 16.94 inches (43.03 cm)
X460-G2-48p-10GE4 15.2 lb (6.9 kg)

Height: 1 RU / 1.73 inches (4.4 cm)

Width: 17.4 inches (44.1 cm)

Depth: 19.2 inches (48.8 cm)
X460-G2-48p-GE4 15.2 lb (6.9 kg)

Height: 1 RU / 1.73 inches (4.4 cm)

Width: 17.4 inches (44.1 cm)

Depth: 19.2 inches (48.8 cm)

16706(X460-G2-48x-10GE4-Base) Specifications (cont.)

Front-Panel Ports (cont.)

Switch Hardware Ports
X460-G2-24p-GE4 • 24 x 10/100/1000BASE-T PoE-Plus - 4 ports are combo ports • 8 x 100/1000BASE-X (SFP) unpopulated ports – 4 ports are combo ports • 4 1GBASE-X SFP (unpopulated ports) • 1 x Serial (console port RJ-45) • 1 x 10/100/1000BASE-T out-of-band management port • 1 x USB port for external USB flash
X460-G2-48p-GE4 • 48 x 10/100/1000BASE-T PoE-Plus • 4 x 1GBASE-X SFP (unpopulated ports) • 1 x Serial (console port RJ-45) • 1 x 10/100/1000BASE-T out-of-band management port • 1 x USB port for external USB flash
X460-G2-16mp-32p-10GE4 • 16 x 100Mb/1/2.5GbE PoE-Plus • 32 x 10/100/1000BASE-T PoE-Plus • 4 x 10GBASE-X SFP+ (unpopulated ports) • 1 x Serial (console port RJ-45) • 1 x 10/100/1000BASE-T out-of-band management port • 1 x USB port for external USB flash
X460-G2 VIM-2x X460-G2 VIM-2x
X460-G2 VIM-2t 2 x 10GBASE-T Ports
X460-G2 VIM-2ss 2 x SummitStack (CX4) Ports
X460-G2 VIM-2q 2 x 40GBASE-X QSFP+ (unpopulated ports)
X460-G2 TM-CLK Clock Module for SyncE and 1588 with 2 mini-BNC connectors for 10MHz and 1PPS signals
Switch ModelWW Maximum Active 10/100/1000 Ports Maximum Active 100/1/2.5GbE Ports Maximum Active 10GbE Ports Maximum Active 40GbE Ports Aggregated Switch Bandwidth Frame Forwarding Rate
X460-G2-48t-10GE4 48 - 6 2 336 Gbps 250 Mpps
X460-G2-48x-10GE4 48 - 6 2 336 Gbps 250 Mpps
X460-G2-48p-10GE4 48 - 6 2 336  Gbps 250 Mpps
X460-G2-48t-GE4 52 - 2 2 224 Gbps 166.7 Mpps
X460-G2-48p-GE4 52 - 2 2 264 Gbps 196.4 Mpps

RJ45 48x Extreme X460 Switch PoE+ Console Port 10GE4 Base 48 Ports 0

RJ45 48x Extreme X460 Switch PoE+ Console Port 10GE4 Base 48 Ports 1



RJ45 48x Extreme X460 Switch PoE+ Console Port 10GE4 Base 48 Ports 2
