Product Details:

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: 900
Get Best Price Contact Now

Detail Information

Model NO.: CX 6200F 24G 4SFP+ Switch (JL724B) Transmission Rate: 10/100/1000Mbps
Ports: ≦8 Operating System: Aruba OS
L3: WLAN/STP/Lldp/Lacp Transport Package: Carton
Specification: 449× 441 × 44mm Trademark: Extreme
Origin: China

Product Description

CX 6100 12G PoE 2G/2SFP+ 139W Switch (JL679A)
The HPE Aruba Networking CX 6200F (JL724B) Switch Series is a next-gen family of stackable access switches ideal for enterprise branch offices, campuses, and SMB networks. With a cloud-centric design that combines a fully programmable OS with the HPE Aruba Networking CX Network Analytics Engine, this switch family extends industry-leading deployment, monitoring, and troubleshooting to the access layer. Make your network ready for tomorrow's unpredictable demands with a powerful Gen7 ASIC architecture to deliver fast, non-blocking performance. HPE Aruba Networking Virtual Stacking Framework (VSF) allows for stacking of up to 8 switches, providing scale and simplified management. This series includes fixed (CX 6200F) and modular (CX 6200M) switches with built-in high speed uplinks and up to 1440W of PoE to support IoT devices such as security cameras and wireless APs.
The HPE Aruba Networking CX 6200F (JL724B) Switch Series provides Layer 3 access switching with high performance, security, and ease of use for enterprise edge, SMB, and branch office networks. A fully distributed architecture with Gen7 ASICs deliver very low latency, increased packet buffering, and adaptive power consumption. Switching and routing are wire-speed to meet the demands of bandwidth-intensive workloads. HPE Aruba Networking Virtual Switching Framework (VSF) allows you to quickly grow your network using high performance front-plane stacking. Create 8 member stacks using built-in SFP+ ports with flexibility to create stacks that span longer distances using long-range transceivers. Deploy wireless access points and IoT devices with HPE Aruba Networking CX 6200 models that support up to 1440W IEEE 802.3at Class 6 Power over Ethernet for up to 60W per port. Flexible, modular switch models support hot-swappable, redundant power supplies and fans for enhanced resiliency.
Product Number
JL724B
Differentiator
24x ports 10/100/1000BASE-T Ports 4x 1/10G SFP ports; PHY-less 1x USB-C Console Port 1x OOBM 1x USB Type-A Host port 1x RJ-45 Console Port Fixed power supply Fixed fans
Ports
24x ports 10/100/1000BASE-T Ports 4x 100M/1/10G SFP+ ports 1x USB-C Console Port 1x RJ-45 Console Port 1x OOBM 1x USB Type-A Host port
Memory and processor
CPU: Quad Core ARM Cortex™ A72 at 1.8 GHz Memory and Flash: 8 GB DDR4 16 GB eMMC
Latency
1 Gbps: 2.28 μSec 10 Gbps: 1.46 μSec
Throughput
Up to 95.2 Mpps
Switching capacity
128 Gbps
Power supply name
Fixed power supply
Input voltage
100V-120V/200V-240V
Power consumption
59W at 230 VAC
Product dimensions
4.39 x 44.2 cm x 32.7 cm
Weight
5.10 kg, max, depending on model
