H3C WX2800X Series New Generation Access Controller

1. Product Overview

The H3C WX2800X series represents a new generation of integrated wireless Access Controllers (AC) and gateways, designed to streamline network architecture and reduce total cost of ownership (TCO) for small to medium-sized businesses. This series, including the WX2860X and WX2880X models, is built on the innovative Comware V7 platform, delivering robust performance, granular user management, comprehensive RF control, and advanced security features. It supports modern wireless standards like 802.11ax (Wi-Fi 6) and offers flexible deployment options, including cloud management and hierarchical AC architectures.

2. Key Characteristics

• All-in-One Design: Integrates AC and gateway functionalities (NAT, PPPoE, VPN) into a single device.
• High-Performance Management: Supports up to 288 APs and 8192 concurrent users (WX2880X).
• Advanced Wireless Standards: Full support for 802.11a/b/g/n/ac/ac wave2/ax (Wi-Fi 6) AP management.
• Enhanced Security: Features WIPS/WIDS, Layer 7 deep packet inspection, and integrated firewall capabilities.
• Flexible Forwarding: Supports both centralized and distributed traffic forwarding modes.
• Intelligent RF Management: Includes auto channel/power adjustment, load balancing, and real-time spectrum guard.

3. Core Technologies & Protocols

The H3C WX2800X leverages the Comware V7 operating system, which introduces multi-core processing, user-mode multi-tasking, and independent application upgrades for improved reliability. It supports a comprehensive suite of networking and security protocols, including CAPWAP for AP management, 802.1X/WPA2/WPA3 for authentication, IPv4/IPv6 dual stack, Bonjour Gateway for Apple devices, and Hotspot 2.0 (802.11u). Advanced features like 802.11k/v/r ensure seamless roaming, while Real-Time Spectrum Guard (RTSG) provides continuous RF monitoring.

4. Working Principle

The H3C WX2800X AC operates as the central brain of a unified wireless network. It establishes secure CAPWAP tunnels with Fit APs distributed across the network, managing their configuration, firmware, and policies centrally. All user authentication requests are processed by the AC, which applies predefined user profiles for access control and QoS. Traffic can be forwarded centrally (tunneled to the AC) or locally (at the AP), depending on the SSID or VLAN configuration. The integrated gateway functionality handles routing, NAT, and VPN services, providing a complete network-in-a-box solution for branch offices.

5. Application & Usage Scenarios

Ideal for small to medium-sized enterprises (SMEs), retail chains, branch offices, and small campuses, the WX2800X series provides a scalable and secure wireless foundation. Typical deployments include:

• Centralized management of H3C Fit APs across multiple locations.
• Unified wired and wireless access with integrated gateway services (PPPoE, NAT, VPN).
• Guest access portals with advanced authentication (802.1X, Portal, MAC).
• High-density environments requiring intelligent load balancing and fast roaming (802.11k/v/r).
• Networks demanding high security with WIPS, layer 7 inspection, and rogue AP detection.

6. Specification & Selection Table

7. Advantages & Selling Points

• Reduced TCO: Combines AC and router functionalities, eliminating the need for separate devices.
• Future-Proof Wi-Fi 6 Support: Manages 802.11ax APs for multi-gigabit wireless speeds and higher capacity.
• Carrier-Class Reliability: Comware V7 OS with features like multi-core control and task isolation ensures high availability.
• Unmatched Security: Offers a deeper level of protection with Layer 7 inspection, real-time WIPS, and integrated threat detection.
• Operational Simplicity: Features like hierarchical AC and cloud management simplify large-scale network operations.

8. Service & Support

Backed by over a decade of industry expertise, we provide comprehensive support for the H3C WX2800X series. Our services include competitive pricing, reliable supply from extensive inventory, and 24/7 customer and technical consultation. We ensure accurate product delivery and offer ongoing technical support to guarantee optimal network performance and integration.

9. Frequently Asked Questions (FAQ)

Q: What is the difference between the WX2860X and WX2880X models?
A: The primary difference is scalability. The WX2880X supports managing twice the number of APs (288) and concurrent users (8192) compared to the WX2860X (144 APs, 4096 users).

Q: Does this controller support the latest Wi-Fi 6 (802.11ax) access points?
A: Yes, the H3C WX2800X series fully supports managing and optimizing H3C's 802.11ax Fit APs.

Q: Can it operate as a router and an AC simultaneously?
A: Absolutely. Its all-in-one design integrates full gateway functions, including PPPoE, NAT, VPN, and firewall, alongside advanced AC capabilities.

Q: What licensing model is used?
A: The base unit manages 0 APs. An enhanced license, such as the LIS-WX-8-BE for 8 APs, must be purchased to manage APs. Licenses are available in increments from 1 to 128 APs.

10. Precautions

• Ensure the operating environment temperature is maintained between 0°C to 45°C.
• Verify compatibility of SFP/SFP+ transceivers (e.g., SFP-GE-LX-SM1310-A, SFP-XG-SX-MM850-E) for fiber connectivity.
• Adhere to local safety and EMC regulations. The device complies with UL 62368-1, IEC 62368-1, FCC, and CE standards.
• Plan the network topology and choose the appropriate forwarding mode (centralized or distributed) based on your WAN bandwidth and latency.
• Regularly update the Comware V7 software to access the latest security patches and features.
