H3c Ewp-Wa6520s-C-Fit Wi-Fi 6 802.11ax Wireless Access Device Built-in >200Mbps
Product Details:
| Brand Name: | H3C |
| Model Number: | EWP-WA6520S-E-FIT |
| Document: | WA6520.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Delivery Time: | Based on inventory |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Model NO.: | EWP-WA6520S-E-FIT | WiFi Antenna Type: | Built-in |
|---|---|---|---|
| Transmission Rate: | >200Mbps | Voltage: | 12 |
| Antenna Gain: | 23dBm | Color: | White |
| Transport Package: | Carton | Specification: | 185*185*35mm |
| Trademark: | H3c | Origin: | China |
| Highlight: | 802.11ax Wireless Access Device,H3c Ewp-Wa6520s-C,Built-in Wireless Access Device |
||
Product Description
H3C EWP-WA6520S-C-FIT Indoor Wi-Fi 6 Access Point
The H3C EWP-WA6520S-C-FIT is an enterprise-grade indoor Wi-Fi 6 (802.11ax) access point designed for high-density environments such as corporate offices, campuses, and healthcare facilities. It delivers a combined dual-band data rate of up to 2.375 Gbps, supports flexible deployment modes (Fit, Cloud, and standalone), and features integrated IoT and intelligent RF management for optimized performance and security.
Key Features
- Wi-Fi 6 (802.11ax) with 2.4 GHz and 5 GHz dual-band support
- Integrated IoT-ready Bluetooth 5.1 module
- Dual Ethernet ports: 2.5G SFP and 10/100/1000M RJ45 with PoE support
- Cloud and Fit mode support with centralized management via H3C AC
- Advanced security including WPA3, WIPS, and native IPv6 support
Core Technologies
The EWP-WA6520S-C-FIT access point incorporates leading Wi-Fi 6 technologies including OFDMA, MU-MIMO, BSS Coloring, and TWT (Target Wake Time) for improved efficiency in high-user-density environments. It also supports H3C’s intelligent operation and maintenance platform for real-time monitoring and automated optimization.
How It Works
The access point operates in either centralized (Fit) or cloud-managed mode. In Fit mode, it is controlled by an H3C wireless controller for seamless roaming and unified policy enforcement. In cloud mode, it supports autonomous operation with remote management via H3C’s cloud platform. The built-in radio resource management (RRM) continuously monitors and adjusts channel and power settings to maintain optimal performance.
Typical Applications
Ideal for enterprises, universities, hospitals, and large public venues where reliable and high-capacity wireless coverage is required. Supports voice, video, and data applications with QoS and application-aware traffic shaping.
Specifications
| Feature | Specification |
|---|---|
| Wi-Fi Standards | 802.11ax/a/b/g/n/ac |
| Max Data Rate | 2.375 Gbps |
| Ethernet Ports | 1×2.5G SFP, 1×Gigabit RJ45 |
| PoE Support | 802.3af/at |
| Antenna | Built-in smart antenna system |
| Operating Temperature | 0°C to 45°C |
| Dimensions | 180×180×32 mm |
Advantages
This Wi-Fi 6 access point offers superior air interface efficiency, better performance in high-interference environments, and support for modern security protocols. Its flexible mounting options and multi-mode operation make it suitable for a wide range of enterprise wireless deployments.
Service & Support
We provide full technical support, 24/7 customer service, and warranty coverage. Bulk order discounts and customized configuration services are available.
Frequently Asked Questions
Q: Does this access point support cloud management?
A: Yes, it can be managed via H3C’s cloud platform or traditional wireless controller.
Q: Is the power adapter included?
A: No, but it supports standard PoE power sourcing equipment.
Q: Can it be used in outdoor environments?
A: No, this model is designed for indoor use only.
Important Notes
Ensure proper ventilation and avoid blocking antenna areas. Use only compatible H3C controllers for full feature support. Firmware updates are recommended for security and performance enhancements.
