Mellanox ConnectX-6 VPI Single Port HDR 200Gb/s InfiniBand & Ethernet Adapter Card, PCIe 3.0/4.0 x16
Product Details:
| Brand Name: | Mellanox |
| Model Number: | MCX653105A-HDAT-SP |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | carton |
| Delivery Time: | 7-10days |
| Payment Terms: | T/T, XTransfer, Western Union, MoneyGram |
| Supply Ability: | 10000pcs/month |
|
Detail Information |
|||
| Products Status: | Stock | Application: | Server |
|---|---|---|---|
| Condition: | New And Original | Type: | Wired |
| Max Speed: | Up To 200 Gb/s | Ethernet Connector: | QSFP56 |
| Model: | MCX653105A-HDAT-SP | Name: | Mellanox ConnectX-6 VPI Single Port HDR 200Gb/s InfiniBand & Ethernet Adapter Card, PCIe 3.0/4.0 X16 |
| Highlight: | MCX653105A-HDAT-SP mellanox network card,Single Port QSFP56 mellanox network card,Single Port QSFP56 mellanox 200gb nic |
||
Product Description
Mellanox ConnectX-6 VPI Single Port HDR 200Gb/s InfiniBand & Ethernet Adapter Card, PCIe 3.0/4.0 x16
MCX653105A-HDAT-SP Mellanox Network card Product Description
ConnectX-Virtual Protocol Interconnect® (VPI) is a groundbreaking addition to the Mellanox ConnectX
series of industry-leading adapter cards. Providing up to two ports of 200Gb/s for InfiniBand and Ethernet
connectivity, sub-600ns latency and 215 million messages per second, ConnectX-6 VPI enables the
highest performance and most flexible solution aimed at meeting the continually growing demands of
data center applications.
In addition to all the existing innovative features of past versions, ConnectX-6 offers a number of
enhancements to further improve performance and scalability.
ConnectX-6 VPI supports up to HDR, HDR100, EDR, FDR, QDR, DDR and SDR InfiniBand speeds as well as up
to 200, 100, 50, 40, 25, and 10Gb/s Ethernet speeds.
MCX653105A-HDAT-SP Mellanox Network card Parameter form
|
item |
Features |
|
Model |
MCX653105A-HDAT-SP |
|
Host Interface |
PCIe Gen 4.0 x16 |
|
Network Protocol Offload |
TCP/IP, UDP/IP, iSCSI, FCoE, NVMe-oF |
|
Data Acceleration and Offloading |
|
|
Intelligent Network Processing |
Packet pacing, congestion control, network virtualization, and more |
|
Security Features |
Secure Boot, Root of Trust, Crypto Acceleration |
|
Operating Systems |
Windows, Linux, VMware |
|
Power Consumption |
21 Watts |
|
Dimensions |
6.6 cm x 16.77 cm |
| Max Speed | HDR and 200GbE |
| Connector Type | QSFP56 |
| Ports | Single |
Features
- Up to 200Gb/s connectivity per port
- Max bandwidth of 200Gb/s
- Up to 215 million messages/sec
- Sub 0.6usec latency
- Block-level XTS-AES mode hardware encryption
- FIPS capable
- Advanced storage capabilities including block-level encryption and checksum offloads
- Supports both 50G SerDes (PAM4) and 25G SerDes (NRZ) based ports
- Best-in-class packet pacing with sub-nanosecond accuracy
- PCIe Gen 3.0 and Gen 4.0 support
- RoHS compliant
- ODCC compatible
Benefits
- Industry-leading throughput, low CPU utilization and high message rate
- Highest performance and most intelligent fabric for compute and storage infrastructures
- Cutting-edge performance in virtualized networks including Network Function Virtualization (NFV)
- Host Chaining technology for economical rack design
- Smart interconnect for x86, Power, Arm, GPU and FPGA-based compute and storage platforms
- Flexible programmable pipeline for new network flows
- Efficient service chaining enablement
- Increased I/O consolidation efficiencies, reducing data center costs & complexity
