Aruba Manufacturer Supply Ap-565 (R4W43A) in Door Wireless Ap
Product Details:
| Brand Name: | Aruba |
| Certification: | ISO9001, RoHS, FCC, CE |
| Model Number: | Ap-565 (R4W43A) |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | carton |
| Delivery Time: | According to quantity |
| Payment Terms: | T/T |
| Supply Ability: | 10000pcs/month |
|
Detail Information |
|||
| Model NO.: | Ap-565 (R4W43A) | WiFi Antenna Type: | External |
|---|---|---|---|
| Transmission Rate: | >200Mbps | Voltage: | 5V |
| Antenna Gain: | 23dBi | Color: | White |
| Security Features: | AES-Ccmp | Warranty: | 12 Months |
| Selling Units: | Single Item | Use: | In Door |
| Condition: | New And Original | Transport Package: | Protecting Boxes |
| Specification: | 165mm× 165mm× 110mm | Trademark: | Aruba |
| Origin: | China | ||
Product Description
AP-565 (R4W43A)
The HPE Aruba Networking AP-565 (R4W43A) Outdoor Access Points provide cost-effective Wi-Fi 6 wireless connectivity in outdoor and environmentally challenging locations. With Wi-Fi 6 capabilities, Bluetooth 5 and 802.15.4/Zigbee radios, and maximum aggregate data rate of 1.49 Gbps, the AP-565 (R4W43A) delivers the speed and reliability needed to bring mediumdensity Wi-Fi 6 outdoors. These Wi-Fi 6 outdoor APs are ready to survive high wind, extreme temperatures, and moisture and can be quickly deployed using Zero Touch Provisioning. HPE Aruba Networking Central provides a single pane of glass for overseeing wired and wireless LANs, WANs, and VPNs.The HPE Aruba Networking AP-565 (R4W43A) Outdoor Access Points provide cost-effective Wi-Fi 6 wireless connectivity in outdoor and environmentally challenging locations. With Wi-Fi 6 capabilities, Bluetooth 5 and 802.15.4/Zigbee radios, and maximum aggregate data rate of 1.49 Gbps, the AP-565 (R4W43A) delivers the speed and reliability needed to bring mediumdensity Wi-Fi 6 outdoors. These Wi-Fi 6 outdoor APs are ready to survive high wind, extreme temperatures, and moisture and can be quickly deployed using Zero Touch Provisioning. HPE Aruba Networking Central provides a single pane of glass for overseeing wired and wireless LANs, WANs, and VPNs.
HPE Aruba Networking AP-565 (R4W43A) Outdoor Access Points are ideal for environmentally challenging locations and can endure extreme temperatures, persistent moisture, precipitation, airborne contaminants, dust, salt sprays, and maximum 165 mph wind speeds. Weatherproof and temperature hardened, this series can handle temperatures ranging from , including full solar loading. With maximum aggregate data rate of 1.49 Gbps (HE80/HE20), the series delivers the speed and reliability needed for most environments. It supports features such as orthogonal frequency-division multiple access (OFDMA), downlink MIMO (MU-MIMO), and target wait time (TWT). Enhanced wireless experience with HPE Aruba Networking ClientMatch technology removes sticky client issues by steering a client to the AP where it receives one of the best radio signals.
HPE Aruba Networking AP-565 (R4W43A) Outdoor Access Points are ideal for environmentally challenging locations and can endure extreme temperatures, persistent moisture, precipitation, airborne contaminants, dust, salt sprays, and maximum 165 mph wind speeds. Weatherproof and temperature hardened, this series can handle temperatures ranging from , including full solar loading. With maximum aggregate data rate of 1.49 Gbps (HE80/HE20), the series delivers the speed and reliability needed for most environments. It supports features such as orthogonal frequency-division multiple access (OFDMA), downlink MIMO (MU-MIMO), and target wait time (TWT). Enhanced wireless experience with HPE Aruba Networking ClientMatch technology removes sticky client issues by steering a client to the AP where it receives one of the best radio signals.
|
Product Number
|
R4W43A
|
|
Differentiator
|
Built-in Omni Directional Antennas 5 GHz Antennas 5.4 dBi 2.4 GHz Antennas 3.2 dBi BLE/802.15.4 Antennas 3.3 dBi Available everywhere except US, Israel, Japan and Egypt
|
|
Certifications
|
CB Scheme Safety, cTUVus UL2043 plenum rating Wi-Fi Alliance certified 802.11a/b/g/n/ Wi-Fi Alliance certified Wi-Fi 6 (802.11ax) Wi-Fi CERTIFIED™ ac (with wave 2 features) Wi-Fi CERTIFIED Location™
|
|
Regulatory
|
FCC/ISED CE Marked RED Directive 2014/53/EU EMC Directive 2014/30/EU Low Voltage Directive 2014/35/EU IEC/EN/UL 62368-1 EN 60601-1-1, EN60601-1-2 Railway Certs: EN 50155:2017-Railway Applications EN 50121-1:2017-Railway EMC EN 50121-3-2-Railway EMC EN 50121-4:2016-Railway Immunity IEC 61373 ed2:2008-Railway Shock and Vibration
|
|
Wi-Fi antenna
|
Built-in omni-directional antennas with 5.4 dBi gain, max, for 5 GHz antennas and 3.2 dBi gain, max, for 2.4 GHz antennas
|
|
Connectivity, standard
|
Wi-Fi 6 (IEEE 802.11ax) Bluetooth 5 and 802.15.4 radio 2.4 GHz–Bluetooth 5: up to 8 dBm transmit power and -95 dBm receive sensitivity Zigbee: up to 8 dBm transmit power and -97 dBm receive sensitivity Up to 4 dBm transmit power (class 2) and -91 dBm receive sensitivity
|
|
Ports
|
E0: 10/100/1000BASE-T (RJ-45)
|
|
Mounting
|
For use with optional mounting kit, see the ordering guide.
|
|
Power consumption
|
Maximum (worst-case) power consumption: 15.6W Maximum (worst case) power consumption in idle mode: 4.2W Maximum (worst case) power consumption in deep-sleep mode: 1.7 Power sources sold separately
|
|
Radio coverage
|
AP type: Outdoor Hardened, Wi-Fi 6 dual radio, 5 GHz 2x2 MIMO and 2.4 GHz 2x2 MIMO Software-configurable dual radio supports 5 GHz (Radio 0) and 2.4 GHz (Radio 1)
|
|
Warranty
|
Limited lifetime warranty. See the warranty duration.
|
|
Product dimensions
|
11 x 16.5 x 16.5 cm
|
|
Weight
|
1.03 kg
|
