48GB Aruba Airwave License LIC-AW JW546AAE
Product Details:
| Brand Name: | Aruba |
| Model Number: | AIRWAVE LIC-AW(JW546AAE) |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Delivery Time: | Based on inventory |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Products Status: | Stock | Warranty: | 1 Year |
|---|---|---|---|
| Condition: | New | Lead Time: | According To Stock |
| Highlight: | 48GB aruba airwave license,aruba airwave license JW546AAE,JW546AAE |
||
Product Description
CONTACT TRACING AND LOCATION TRACING
Historical Wi-Fi location data from AirWave can be exported, analyzed, and displayed using Aruba Central or a third-party data analysis tool. This includes simple search queries can be run on a per-client basis to identify nearby clients and contact duration. This is intended to expediently provide data for appropriate enterprise and public health entities to manage and counteract potential COVID-19 outbreaks.
| Category | Pro Appliance | Pro Appliance (Gen10) | Central Ready Appliance |
| Appliance Specifications | |||
| CPU |
8-core 2.6 Ghz HPE DL360 Gen9 E5-2640v3 |
8 Core Intel Xeon-S 4110 @ 2.10 Ghz - HPE DL360 Gen10 |
2 20-core Intel Xeon-G 6138 @ 2.0 GHz - HPE DL360 Gen10 |
| Memory | 48GB | 48GB | 512GB |
| Storage |
6 300GB 12G SAS 15K 2.5in SC ENT HDD |
6 300GB SAS 15K SFF SC DS HDD | 4 1TB SSD HDD (2 TB in RAID 10) |
| Appliance Scalability | |||
| Maximum Managed Devices | 1,500 | 1,500 | 4,000 |
| Power | |||
| Power |
500W FS Plat Hot Plug Power Supply |
500W FS Plat Hot Plug Power Supply |
500W FS Plat Hot Plug Power Supply |
| Power Supply | Optional redundant power supply | Optional redundant power supply | Optional redundant power supply |
| AC Input Voltage | 110/220 VAC Auto-Selecting | 110/220 VAC Auto-Selecting | 110/220 VAC Auto-Selecting |
| AC Input Frequency | 50/60 Hz Auto-Selecting | 50/60 Hz Auto-Selecting | 50/60 Hz Auto-Selecting |
| Physical | |||
| Rackmount |
1U SFF Easy Install Rail 1U Cable Management Arm |
1U SFF Easy Install Rail 1U Cable Management Arm |
1U SFF Easy Install Rail 1U Cable Management Arm |
|
Dimensions (H x W x D) |
1.7 x 17.1 x 27.5 inches (4.32 x 43.47 x 69.85 cm) | 1.7 x 17.1 x 27.5 inches (4.32 x 43.47 x 69.85 cm) | 1.7 x 17.1 x 27.8 inches (4.29 x 43.46 x 70.7 cm) |
| Weight | 33.3 lb. (15.31 kg) max | 33.3 lb. (15.31 kg) max | 35.9 lb. (16.27 kg) max |
| HP SmartDrives |
8 + 2 SFF/4 LFF max, HDD/SSD |
8 + 2 SFF/4 LFF max, HDD/SSD |
4 LFF SAS/SATA/SSD 8 or 10 SFF SAS/SATA/SSD |
|
Networking |
4 x 1GbE embedded + FlexibleLOM slot | 4 x 1GbE embedded + Flexible LOM slot or HPE FlexFabric 10Gb 4-Port 536FLR-T Adapter | 2 x 10GbE and 4 x 1GbE embedded + Flexible-LOM slot |
| VGA/serial/USB ports | Front VGA opt, rear VGA standard, and serial opt., 5 USB 3.0 | Front VGA opt, rear VGA standard, and serial opt., 5 USB 3.0 |
Front VGA opt, rear VGA standard, and serial opt., 5 USB 3.0, iLO Remote Mgmt, MicroSD Slot |
| Industry compliance |
ASHRAE A3 and A4, lower idle power |
ASHRAE A3 and A4, lower idle power |
ASHRAE A3 and A4, lower idle power |
| Warranty | |||
| Hardware | 1 year parts | 1 year parts | 1 year parts |
| Software | 90 days | 90 days | 90 days |
