256AP Aruba Wireles Controller 7205-RWJW735A 4XCombo 2XSFP
Product Details:
| Brand Name: | Aruba |
| Model Number: | 7210-RWJW743A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Delivery Time: | Based on inventory |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Products Status: | Stock | Warranty: | 1 Year |
|---|---|---|---|
| Condition: | New | Lead Time: | According To Stock |
| 10/100/1000BASE-T: | 4xCombo | 1000BASE-X: | 4xCombo |
| 0G Ports (10G Or 1G Supported): | 2xSFP+ | Maximum VLAN: | 4,096 |
| Maximum Concurrent Users / Devices: | 8,192 | Concurrent GRE Tunnels: | 4,096 |
| Firewall Throughput (Gbps): | 12 | Wired Bridged Throughput (Gbps): | 12 |
| Encrypted Throughput 3DES (Gbps): | 5 | Form Factor/footprint: | 1xRU |
| Weight: | 4.95 Kg (10.19 Lbs.) | Type: | Controller |
| Highlight: | 256AP Aruba Wireless Controller,7205 Aruba Wireless Controller,256AP aruba 7205 wireless controller |
||
Product Description
Flexible use cases
upport data centers, public cloud, and SaaS routing by deploying the 7200 Series as a controller with ArubaOS or as a SD-Branch gateway.
Up to 2,048 access points and 100 Gbps of throughput
Providing connectivity for up to 32,728 concurrent users or client devices, the 7200 Series is ideal for the most demanding enterprise, higher education, and large public venue requirements.
Dynamic Segmentation for simplicity and security
Enforcing granular user, device, and application policies over both access points and network switches means there's no need to configure separate VLANs, ACLs, and subnets.
Supports for Wi-Fi standards
Offering WPA and Enhanced Open as part of 802.11ax, the 7000 provides enhanced security and backwards compatibility.
Machine learning and advanced analytics
AirMatch applies machine learning to automate RF optimization and adapt to changing WLAN conditions, while ClientMatch improves client roaming and resolves sticky client issues.
PERFORMANCE AND CAPACITY
| Features | 7205 | 7210 | 7220 | 7240XM | 7280 | |||||||||||
| Maximum campus or remote AP licenses | 256 | 512 | 1,024 | 2,048 | 2,048 | |||||||||||
| Maximum concurrent users/devices | 8,192 | 16,384 | 24,576 | 32,768 | 32,768 | |||||||||||
| Maximum VLANs | 4,096 | 4,096 | 4,096 | 4,096 | 4,096 | |||||||||||
| Active firewall sessions | 1 million (M) | 2M | 2M | 2M | 2M | |||||||||||
| Concurrent GRE tunnels | 4,096 | 8,192 | 16,384 | 32,768 | 32,768 | |||||||||||
| Concurrent IPsec sessions | 8,192 | 16,384 | 24,576 | 32,768 | 32,768 | |||||||||||
| Concurrent SSL sessions | 4,096 | 8,192 | 8,192 | 8,192 | 8,192 | |||||||||||
| Firewall throughput (Gbps) | 12 | 20 | 40 | 40 | 100 | |||||||||||
| Wired Bridged Throughput (Gbps) | 12 | 20 | 40 | 40 | 100 | |||||||||||
| Encrypted throughput 3DES (Gbps) | 5 | 7 | 25 | 28 | 57 | |||||||||||
| Encrypted throughput AES-CBC-256 (Gbps) | 5 | 7 | 22 | 30 | 46 | |||||||||||
| Encrypted throughput AES-CCM (Gbps) | 5 | 7 | 20 | 29 | 75 | |||||||||||
| Encrypted throughput AES-GCM-256 (Gbps) | 5 | 7 | 26 | 35 | 70 | |||||||||||
| INTERFACES AND INDICATORS | ||||||||||||||||
| Features | 7205 | 7210 | 7220 | 7240XM | 7280 | |||||||||||
| Form factor/footprint | 1xRU | 1xRU | 1xRU | 1xRU | 1xRU | |||||||||||
| 10/100/1000BASE-T | 4xCombo | 2xCombo | 2xCombo | 2xCombo | – | |||||||||||
| 1000BASE-X | ||||||||||||||||
| 10G Ports (10G or 1G supported) | 2xSFP+ | 4xSFP+ | 4xSFP+ | 4xSFP+ | 8xSFP+ | |||||||||||
| 40G Ports | – | – | – | – | 2xQSFP+ | |||||||||||
| USB 2.0 | 2 | 1 | 1 | 1 | 1 | |||||||||||
| Management/status LEDs | Yes | Yes | Yes | Yes | Yes | |||||||||||
| LINK/ACT and status LEDs | Yes | Yes | Yes | Yes | Yes | |||||||||||
| LCD panel and navigation buttons | Yes | Yes | Yes | Yes | Yes | |||||||||||
| Console port | Micro USB, RJ-45 | Mini USB, RJ-45 | Mini USB, RJ-45 | Mini USB, RJ-45 | Micro USB, RJ-45 | |||||||||||
| Out-of-band management port | Yes | No | No | No | Yes | |||||||||||
| PHYSICAL | ||||||||||||||||
| Features | 7205 | 7210 | 7220 | 7240XM | 7280 | |||||||||||
| Dimensions (HxWxD) | (H) 4.4 cm x (W) 44.2 cm x (D) 33.4 cm (1.75” x 17.38” x 13.13”) |
(H) 4.4 cm x (W) 44.5 cm x (D) 44.5 cm (1.75” x 17.5” x 17.5”) |
(H) 4.4 cm x (W) 44.2 cm x (D) 40.1 cm (1.73” x 17.40” x 15.79”) |
|||||||||||||
| Weight | 4.95 kg (10.19 lbs.) | 7.45 kg (16.43 lbs.) | 7.9 kg (17.41 lbs) | |||||||||||||
| MTBF (Hours) | 129,597 (@40C) | 106,536 (@40C) | 113,751 (@40C) | 116,590 (@40C) | 281,896 (@45C) | |||||||||||
| ENVIRONMENTAL RANGE | ||||||||||||||||
| Features | 7205 | 7210 | 7220 | 7240XM | 7280 | |||||||||||
| Operating Temperature | 0° C to 40° C | |||||||||||||||
| Storage Temperature | -40° C to 70° C | |||||||||||||||
| Humidity/Storage Humidity | 10% to 95%, NC | 5% to 95%, NC | 5% to 95%, NC | 5% to 95%, NC | 5% to 95%, NC | |||||||||||
| Operating Altitude | 10,000 feet | |||||||||||||||
| Acoustic Noise1 | 49 dBA | 52.9 dBA | 47.1 dBA | |||||||||||||
| Maximum Heat Dissipation (BTU/hour) | 260 | 375 | 427 | 563 | 819 | |||||||||||
| Maximum Power Consumption | 75.2W | 110W | 125W | 165W | 240W | |||||||||||
| Power Source | Internal power supply | 350-watt AC or DC power supply | 550-watt power supply | |||||||||||||
| 1Sound power per ETSI 300 753 in accordance with ISO 7779 | ||||||||||||||||
| POWER ADAPTER AND SUPPLY SPECIFICATIONS | ||||||||||||||||
| Features | 350-watt AC | 350-watt DC | 550-watt | |||||||||||||
| Input voltage range | 100 VAC to 240 VAC | DC -48V to DC -60V | 100 VAC to 240 VAC | |||||||||||||
| Output Voltage | +12VDC, 29.16A | +12VDC, 29.16A | +12VDC, 29.16A | |||||||||||||
| Input frequency | 50-60 Hz | 50-60 Hz | 50-60 Hz | |||||||||||||
| AC line input current (steady state) | 5 - 2.5A | 5 - 2.5A | 7.1 - 3.4A | |||||||||||||
| Operating Temperature | -5o to +55o C | -5o to +55o C | -5o to +55o C | |||||||||||||
| Cooling | Internal fan (Air flow rear to front) |
Internal fan (Air flow rear to front) |
819 Internal fan (Air flow rear to front) | |||||||||||||
| Weight | 1.3 kg (2.8 lbs) | 1.3 kg (2.8 lbs) | 0.87 kg (1.9 lbs) | |||||||||||||
| REGULATORY AND SAFETY COMPLIANCE | ||||||||||||||||
| Features | 7205 | 7210 | 7220 | 7240XM | 7280 | |||||||||||
| Regulatory SKU information | ARCN7205 | ARCN0100 | ARCN0101 | ARCN0102 | ARCN7280 | |||||||||||
| Minimum ArubaOS Release | 6.4.3.0 | 6.2.0.0 | 6.2.0.0 | 6.4.4.0 | 6.5.4.0 or 8.3.0.0 | |||||||||||
| 802.11ax (Wi-Fi 6), AOS 8.4; WI-FI CERTIFIED WPA3™, AOS 8.4; WI-FI CERTIFIED Enhanced Open™, AOS 8.4 |
||||||||||||||||
| Regulatory and Safety Compliance | FCC Part 15 Class A CE | |||||||||||||||
| Industry Canada Class A | ||||||||||||||||
| VCCI Class A (Japan) | ||||||||||||||||
| EN 55022 Class A (CISPR 22 Class A), EN 61000-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 55024, AS/NZS 3548 |
||||||||||||||||
| UL 60950, EN60950 | ||||||||||||||||
| CAN/CSA 22.2 #60950 | ||||||||||||||||
| CE mark, cTUVus, CB, C-tick, Anatel, NOM, MIC | ||||||||||||||||
| Telco | Common Language Equipment Identifier (CLEI) Code | |||||||||||||||
