NVIDIA ConnectX-6 Lx MCX623106AN-CDAT 50Gb/s Dual-Port 25GbE SmartNIC – PCIe Gen4 x8, 75 Mpps, RoCE, OCP 3.0
Product Details:
| Brand Name: | Mellanox |
| Model Number: | MCX631102AN-ADAT |
| Document: | connectx-6-infiniband.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Delivery Time: | Based on inventory |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Products Status: | Stock | Condition: | New And Original |
|---|---|---|---|
| Technology: | Ethernet | Network Interface: | Two SerDes Lanes Supporting 25Gb/s Per Lane, For Various Port Configurations: -2x 10/25 GbE -1x 50GbE |
| Host Interface: | PCIe Gen 4.0, 3.0, 2.0, 1.1 16.0, 8.0, 5.0, 2.5 GT/s Link Rate 8 Lanes Of PCIe MSI/MSI-X Mechanisms Advanced PCIe Capabilities | Speed: | 25Gbps |
| Connectors: | 2 X SFP28 | Interface: | PCIe 4.0 X8 |
| Highlight: | NVIDIA ConnectX-6 Lx 50Gb/s SmartNIC,Dual-Port 25GbE PCIe Gen4 Network Card,OCP 3.0 RoCE SmartNIC with warranty |
||
Product Description
NVIDIA ConnectX-6 Lx MCX623106AN-CDAT 50Gb/s SmartNIC
High-performance 25/50GbE Ethernet SmartNIC designed for modern enterprise and cloud data centers with advanced security and acceleration features.
Product Overview
The NVIDIA ConnectX-6 Lx MCX623106AN-CDAT is a dual-port 25/50GbE Ethernet SmartNIC delivering up to 50 Gb/s total bandwidth with PCIe Gen4 x8 host interface. This OCP 3.0 Small Form Factor adapter provides exceptional performance, advanced security, and accelerated networking at an optimized total cost of ownership.
Featuring Zero-Touch RoCE for simplified RDMA deployments, inline IPsec encryption/decryption acceleration, hardware root-of-trust, and ASAP² SDN offload, this SmartNIC enables secure, high-performance networking for virtualization, NFV, and cloud-native environments.
Key Features
- Up to 50 Gb/s total bandwidth (2x 25GbE or 1x 50GbE)
- Line speed message rate of 75 Mpps
- PCIe Gen 4.0 x8 host interface (backward compatible with Gen3)
- OCP 3.0 Small Form Factor for high-density servers
- Zero-Touch RoCE - no PFC or ECN configuration required
- ASAP² SDN acceleration for overlay networks
- Inline hardware IPsec encryption and decryption
- Hardware root-of-trust with secure boot and secure firmware update
- SR-IOV and VirtIO acceleration for virtualization
- Connection tracking hardware offload
Technology & Architecture
The ConnectX-6 Lx architecture integrates advanced acceleration engines that offload critical networking functions from the host CPU:
ASAP² Acceleration
Offloads the SDN data plane to the SmartNIC, delivering line-rate performance for overlay networks including VXLAN, GENEVE, NVGRE, MPLS, and GTP.
Zero-Touch RoCE
Eliminates the need for Priority Flow Control or Explicit Congestion Notification configuration, enabling simple, resilient RDMA deployments at scale.
Inline IPsec Crypto
Hardware-accelerated encryption and decryption (AES-XTS 256/512-bit) for secure data-in-transit with negligible performance impact.
Hardware Root-of-Trust
Secure boot using RSA cryptography and device-unique key cloning protection ensures firmware authenticity and supply chain security.
Typical Deployments
- Enterprise Data Centers: High-performance 25/50GbE server connectivity
- Cloud and NFV Infrastructure: SDN acceleration for virtualized environments
- AI and Machine Learning Clusters: Low-latency RDMA for distributed workloads
- Security-Sensitive Environments: IPsec encryption with hardware security
- Telecommunications: NFV acceleration with MPLS, GTP, and connection tracking
Specifications
| Parameter | Details |
|---|---|
| Part Number | MCX623106AN-CDAT |
| Product Family | NVIDIA ConnectX-6 Lx |
| Ports | 2x 25GbE or 1x 50GbE (SFP28 / QSFP28) |
| Total Bandwidth | Up to 50 Gb/s |
| Message Rate | 75 Mpps (line rate) |
| Host Interface | PCIe Gen 4.0 x8 (compatible with Gen3, Gen2, Gen1) |
| Form Factor | OCP 3.0 Small Form Factor |
| Crypto Acceleration | Inline IPsec (AES-XTS 256/512-bit) |
| Security | Hardware root-of-trust, secure boot, secure firmware update |
| RoCE | Zero-Touch RoCE, RoCE over IPsec |
| SDN Offload | ASAP²: VXLAN, GENEVE, NVGRE, MPLS, GTP, VXLAN-GPE |
| Virtualization | SR-IOV, VirtIO acceleration |
| Management | NC-SI, MCTP, PLDM |
| Remote Boot | PXE, iSCSI, UEFI (x86 and Arm) |
| Warranty | 1-year limited hardware warranty |
Key Benefits
Superior Performance: 75 Mpps line-rate message processing with PCIe Gen4 x8 bandwidth
Simplified RoCE: Zero-Touch RoCE eliminates complex PFC/ECN configuration
Built-in Security: Inline IPsec, hardware root-of-trust, and secure boot
SDN Ready: ASAP² offloads overlay tunneling and SDN data plane
Optimized for Virtualization: SR-IOV and VirtIO acceleration
OCP 3.0 SFF: Open Compute Project standard form factor
Frequently Asked Questions
What is the port configuration for MCX623106AN-CDAT?
This adapter supports two ports of 25GbE (SFP28) or a single port of 50GbE (QSFP28). Please verify your specific configuration requirements before ordering.
What is Zero-Touch RoCE?
ZTR allows RoCE to operate seamlessly on existing Ethernet networks without requiring Priority Flow Control or Explicit Congestion Notification configuration, simplifying RDMA deployments.
Is this card compatible with PCIe Gen3 servers?
Yes, the adapter is PCIe Gen4 x8 and is fully backward compatible with PCIe Gen3, Gen2, and Gen1 slots.
Precautions
- Form factor: This is an OCP 3.0 Small Form Factor adapter - ensure server compatibility
- Power and cooling: Verify server power budget and airflow requirements
- Firmware: Always use official NVIDIA firmware updates
- ESD precautions: Follow standard ESD handling procedures
- Cable compatibility: Use SFP28 or QSFP28 cables meeting IEEE specifications
Company Introduction
Hong Kong Starsurge Group Co., Limited is a technology-driven provider of network hardware, IT services, and system integration solutions. Founded in 2008, the company serves customers worldwide with products including network switches, NICs, wireless access points, controllers, cables, and related networking equipment.
Backed by an experienced sales and technical team, Starsurge supports industries such as government, healthcare, manufacturing, education, finance, and enterprise. The company focuses on reliable quality, responsive service, and tailored solutions for efficient, scalable network infrastructure.
Buyer Checklist
- Confirm server has OCP 3.0 SFF slot
- Verify required port configuration (2x 25GbE or 1x 50GbE)
- Check PCIe slot availability (Gen4 x8 recommended)
- Confirm OS/driver support for ConnectX-6 Lx
- Evaluate security requirements (IPsec, RoT)
- Consider RoCE adoption for storage/AI workloads
- Ensure appropriate SFP28/QSFP28 optics or DAC cables
