NVIDIA MCP4Y10-N002 2x400Gb/s OSFP to OSFP Passive DAC Cable – 2m, 800Gb/s Aggregate, InfiniBand & Ethernet
Product Details:
| Brand Name: | Mellanox |
| Model Number: | MCP4Y10-N002(980-9IA0I-00N002) |
| Document: | mcp4y10-nxxx-twin-port-2x40...ns.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Delivery Time: | Based on inventory |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Type: | Optical Cable | Conductor Type: | Solid |
|---|---|---|---|
| Certification: | CE, ISO, RoHS, CCC, VDE | Production Capacity: | 5000 |
| Cover Material: | Lf (Lead Free) Hf (Halogen Free) PCB | Material Shape: | Round Wire |
| Specification: | 2m | Origin: | India / Israel / China |
| Highlight: | NVIDIA OSFP passive DAC cable 2m,800Gb/s OSFP cable InfiniBand Ethernet,NVIDIA MCP4Y10-N002 DAC cable 400Gb/s |
||
Product Description
NVIDIA MCP4Y10-N002 2x400Gb/s OSFP Passive DAC Cable
The NVIDIA MCP4Y10-N002 is a twin-port OSFP to OSFP passive Direct Attach Copper cable delivering 800Gb/s aggregate data rate across two 400Gb/s ports. This cost-effective, ultra-low latency solution utilizes 8 channels of 100G-PAM4 modulation for high-performance data center connectivity.
Part Number: MCP4Y10-N002
Length: 2.0 m
Wire Gauge: 26 AWG
Connector: OSFP (Finned Top)
Data Rate: 800 Gb/s Aggregate
Ports: 2x 400Gb/s
Key Features
- Twin-port OSFP to twin-port OSFP passive DAC
- 2x 400Gb/s data rate (800Gb/s aggregate)
- 8 channels of 100G-PAM4 modulation
- Ultra-low latency, near-zero power consumption
- 2.0 m length, 26 AWG wire gauge
- Hot-pluggable, SFF-8665 compliant
- Supports InfiniBand and Ethernet (auto-detected)
- I²C management interface with EEPROM
- LSZH (Low Smoke Zero Halogen) jacket
- RoHS, LF, HF compliant
Technology Overview
Direct Attach Copper (DAC) cables offer the lowest-cost, lowest-latency, and near-zero power consumption of any high-speed interconnect. By eliminating active electronics, passive DACs provide a simple, reliable, and energy-efficient physical layer for short-reach connections within racks and between adjacent switches.
The OSFP (Octal Small Form Factor Pluggable) connector delivers 8 high-speed lanes in a compact package, enabling 800Gb/s aggregate throughput while maintaining excellent signal integrity. Supports InfiniBand NDR (400Gb/s per port) and Ethernet 800GBASE-CR8 / 400GBASE-CR4 / 200GBASE-CR2 / 100GBASE-CR1 protocols.
Typical Deployments
- Quantum-2 InfiniBand switch-to-switch interconnect
- Spectrum-4 Ethernet switch-to-switch cabling
- Switch-to-DGX-H100 server connectivity
- Rack-internal connections in HPC and AI clusters
- Spine-leaf topologies for high-performance data centers
Compatibility
- Switches: NVIDIA Quantum-2, Spectrum-4 (OSFP ports)
- Servers: NVIDIA DGX-H100 (flat-top variant available)
- Protocols: InfiniBand NDR, Ethernet (auto-detected)
- Standards: SFF-8665, SFF-8636, CMIS Rev 5.0
- Connector: OSFP (finned top, both ends)
Specifications
| Category | Detail |
|---|---|
| Model | MCP4Y10-N002 |
| Type | Passive Direct Attach Copper (DAC) |
| Data Rate | 2x 400Gb/s (800Gb/s aggregate) |
| Modulation | 8 channels of 100G-PAM4 |
| Length | 2.0 m (±50 mm tolerance) |
| Wire Gauge | 26 AWG, 2x8 pairs |
| Cable Diameter | 8.9 ±0.03 mm |
| Connector Type | OSFP (finned top, both ends) |
| Supply Voltage | 3.3 V (single supply) |
| Power Consumption | 0.1 W (near-zero) |
| Operating Case Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Operating Relative Humidity | 5% to 85% |
| Characteristic Impedance | 100Ω nominal (90-110Ω range) |
| Minimum Bend Radius | Assembly: 89 mm; Repeated/Single bend: 10x/5x OD |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Standards Compliance | SFF-8665, SFF-8636, CMIS Rev 5.0 |
| Regulatory Compliance | RoHS, LF, HF, CE, FCC, VCCI, ICES, RCM, CB, TUV, UKCA |
| Management Interface | I²C, EEPROM with product configuration data |
Product Series Selection Guide
| Part Number | Length | Wire Gauge | Connector Type |
|---|---|---|---|
| MCP4Y10-N00A | 0.5 m | 30 AWG | OSFP (finned) |
| MCP4Y10-N001 | 1.0 m | 30 AWG | OSFP (finned) |
| MCP4Y10-N01A | 1.5 m | 30 AWG | OSFP (finned) |
| MCP4Y10-N002 | 2.0 m | 26 AWG | OSFP (finned) |
| MCP4Y10-N00A-FLT | 0.5 m | 30 AWG | OSFP (flat top) |
| MCP4Y10-N001-FLT | 1.0 m | 30 AWG | OSFP (flat top) |
Note: Flat-top variants (-FLT) are designed for liquid-cooled switches and DGX-H100 systems. MCP4Y10-N002 is a 2m cable with 26 AWG gauge and finned-top connectors on both ends.
Performance Advantages
Lowest Cost
Passive DAC eliminates expensive optical components and active electronics.
Near-Zero Power
0.1W typical consumption - significantly reduces data center power and cooling costs.
Ultra-Low Latency
Direct copper connection provides the lowest possible signal delay.
High Density
OSFP form factor enables 800Gb/s aggregate in a compact cable assembly.
Plug-and-Play
Auto-detects InfiniBand or Ethernet protocol; no configuration required.
Buyer Checklist
- Confirm length required (2.0m = MCP4Y10-N002)
- Verify connector type: finned (standard) vs flat top (-FLT)
- Check switch port type: OSFP required
- Ensure cable management space meets bend radius requirements
- Confirm protocol (InfiniBand or Ethernet) auto-detected
Frequently Asked Questions
What is the maximum length for this cable?
2.0 meters. For longer distances, consider active optical cables or optical transceivers.
Does this cable support both InfiniBand and Ethernet?
Yes, the firmware auto-detects the protocol of the connected switch and configures accordingly.
What is the difference between finned and flat top?
Finned top is standard; flat top (-FLT variants) are designed for liquid-cooled switches and DGX-H100 systems.
Is this cable hot-pluggable?
Yes, OSFP connectors are hot-pluggable - no need to power down the switch or server.
Installation Precautions
- Observe ESD handling precautions during installation
- Do not exceed the minimum bend radius: 89mm assembly, 10x OD for repeated bends
- Follow NVIDIA Cable Management Guidelines to avoid physical damage
- Protect connectors with supplied caps until installation
- Confirm connector type (finned vs flat top) matches your system
Service & Support
- 1-year standard warranty
- Technical support via email / phone
- RMA services for defective units
- Global logistics and delivery
- Compliance certifications available on request
