KJ Series Modular Jack, RJ45, Cat6A Shielded, Silver

The CommScope KJX-6A represents a breakthrough in network connectivity with its innovative tool-free termination technology. This Category 6A shielded modular jack delivers exceptional 10 Gigabit Ethernet performance while eliminating the need for specialized termination tools, significantly reducing installation time and complexity. The sleek silver housing provides a premium appearance that complements modern network infrastructure designs while ensuring robust performance in demanding environments.

This advanced modular jack is engineered to meet the highest industry standards, supporting frequencies up to 500 MHz for reliable 10GbE transmission. The tool-free termination system makes this Category 6A modular jack ideal for rapid deployments, maintenance operations, and installations where tool access may be limited. As part of the innovative KJ Series, this modular jack combines cutting-edge technology with proven reliability for critical network applications.

• Revolutionary tool-free termination technology
• Category 6A performance for 10GbE up to 100m
• IEEE 802.3bt Type 4 PoE++ support (90W)
• Premium silver housing for professional appearance
• 12 units per package in protective tray
• Keystone footprint for universal compatibility

The revolutionary tool-free termination system of the KJX-6A modular jack represents a significant advancement in network installation efficiency. This Category 6A modular jack eliminates the need for specialized punch-down tools, reducing installation time by up to 70% compared to traditional termination methods. The innovative IDC mechanism ensures consistent, reliable connections without compromising the exceptional performance requirements of Category 6A systems.

This tool-free modular jack features an intuitive termination process that requires no technical expertise, making it ideal for quick deployments, field service operations, and installations in confined spaces. The termination system maintains proper pair untwist control and conductor seating, ensuring optimal signal integrity and compliance with Category 6A performance standards. The tool-free design significantly reduces the risk of installation errors and improves overall deployment consistency.

This Category 6A modular jack delivers robust 10 Gigabit Ethernet performance supporting transmission frequencies up to 500 MHz. The fully shielded design provides comprehensive protection against electromagnetic interference and alien crosstalk, ensuring reliable performance in high-density installations. The modular jack complies with ANSI/TIA-568.2-D and ISO/IEC 11801 Class EA standards, guaranteeing interoperability with other certified components.

The advanced contact design features gold-plated beryllium copper contacts with 1.27 μm plating thickness, ensuring low contact resistance and long-term reliability. This Category 6A modular jack maintains consistent performance through more than 3,000 mating cycles, providing exceptional durability for frequently accessed connections in data centers, commercial buildings, and industrial environments.

The KJX-6A modular jack fully supports IEEE 802.3bt Type 4 Power over Ethernet applications, delivering up to 90W of power to connected devices. This Category 6A modular jack is specifically engineered to handle the thermal challenges associated with high-power PoE applications, ensuring reliable operation even under maximum load conditions. The robust construction maintains performance through more than 3,000 mating cycles with active PoE connections.

This modular jack is ideal for powering next-generation devices including high-performance wireless access points, advanced security systems with heating elements, digital signage, and building automation equipment. The enhanced power delivery capabilities make this Category 6A modular jack perfectly suited for modern IoT deployments and smart building applications requiring both high-speed data transmission and significant power delivery.

This innovative modular jack features a standard keystone footprint, ensuring compatibility with a wide range of faceplates, patch panels, and surface mount boxes. The tool-free termination system accommodates both solid (26-22 AWG) and stranded (24 AWG) conductors, supporting cable diameters up to 9.0 mm for maximum installation flexibility. The modular jack's dimensions (21.5 mm height * 17.2 mm width * 38.3 mm depth) are optimized for various installation scenarios.

CommScope's KJX-6A modular jack meets the most stringent international standards including ANSI/TIA-568.2-D and ISO/IEC 11801 Class EA requirements. The product carries comprehensive environmental certifications including RoHS, China-RoHS, UK-ROHS, and REACH-SVHC compliance. The UL 94 V-0 flammability rating ensures maximum fire safety in commercial and data center installations.

The modular jack construction utilizes premium materials including polycarbonate and Zamak for housing components and gold-plated beryllium copper contacts. This material selection ensures mechanical durability, excellent electrical performance, and long-term reliability. The product is RCM certified for Australian and New Zealand markets and supports global deployment requirements.

How does the tool-free termination work?
The innovative IDC mechanism allows conductors to be inserted and secured without tools, using an intuitive lever or push mechanism that ensures proper connection and maintains performance standards.

What are the time savings with tool-free termination?
Installation time can be reduced by up to 70% compared to traditional punch-down methods, with typical terminations completed in under 30 seconds without specialized tools.

Is performance compromised with tool-free termination?
No, the tool-free modular jack maintains full Category 6A performance compliance, with rigorous testing confirming equivalent performance to traditionally terminated jacks.

What packaging format is used?
The modular jacks are packaged in quantities of 12 units in protective trays within boxes, ensuring damage-free shipping and organized inventory management.

Are there any installation limitations?
This modular jack is not recommended for shallow wall boxes due to its depth, and is optimized for standard depth boxes, patch panels, and surface mount applications.

• Verify adequate depth in wall boxes before installation (not recommended for shallow boxes)
• Follow manufacturer's tool-free termination procedure for optimal results
• Maintain proper cable bend radius during installation
• Ensure complete conductor insertion in termination channels
• Verify shield continuity for proper EMI protection
• Test completed connections for performance verification
• Use T568A or T568B wiring scheme consistently throughout installation
• Document installation details for future maintenance reference
