HPE Aruba Networking AP-567EX (R4W66A) Hazardous Location Access Points
Product Details:
| Brand Name: | Aruba |
| Model Number: | R4W66A |
| Document: | HPE Aruba Networking 560EX ...nw.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | outer box |
| Delivery Time: | Based on inventory |
| Payment Terms: | T/T |
| Supply Ability: | Supply by project/batch |
|
Detail Information |
|||
| Model: | AP-567EX (R4W66A) | Wi-Fi Standard: | Wi-Fi 6 (802.11ax) |
|---|---|---|---|
| Antennas: | Integrated Directional (90°H X 90°V) | Max Data Rate: | 1.49 Gbps |
| Ethernet Port: | 1x 10/100/1000BASE-T (PoE+) | Power Consumption: | 15.6W Max |
| Highlight: | 16 AP 7005 aruba controller,Wireles 7005 aruba controller,7005 aruba ap controller |
||
Product Description
HPE Aruba Networking 560EX Series Hazardous Location Access Points
1. Product Overview
The HPE Aruba Networking 560EX Series is a ruggedized, industrial-grade Wi-Fi 6 (802.11ax) Access Point designed for deployment in hazardous and outdoor environments. Engineered to withstand extreme temperatures, moisture, and airborne contaminants, this AP delivers high-performance wireless connectivity with advanced security and IoT capabilities. The Aruba AP-567EX model (P/N: R4W66A) features integrated directional antennas optimized for focused coverage in challenging conditions.
2. Key Characteristics
- Wi-Fi 6 (802.11ax) with OFDMA and MU-MIMO
- IP66/67 rated for dust and water resistance
- Operates in temperatures from -40°C to +55°C
- Integrated Bluetooth 5 and Zigbee (802.15.4) for IoT
- Class 1 Division 2 and ATEX Zone 2 certified
- Advanced Cellular Coexistence (ACC) technology
- Supports WPA3, Enhanced Open, and VPN tunneling
3. Core Technologies
The 560EX Series leverages Wi-Fi 6 technologies including Orthogonal Frequency-Division Multiple Access (OFDMA), Multi-User MIMO (MU-MIMO), and Target Wake Time (TWT) for efficient client handling and power savings. It also features Aruba's ClientMatch AI technology for intelligent client steering and dynamic segmentation via Policy Enforcement Firewall (PEF).
4. How It Works
The Access Point establishes wireless connections using dual-band radios (2.4 GHz and 5 GHz), managing client devices through optimized airtime scheduling and interference mitigation. In hazardous locations, the sealed enclosure and surge-protected interfaces ensure continuous operation even under environmental stress. The integrated IoT radio supports Bluetooth and Zigbee for location services and sensor connectivity.
5. Applications
Ideal for oil and gas facilities, chemical plants, mining operations, ports, utilities, and other industrial or outdoor settings where reliable Wi-Fi and IoT connectivity are required under challenging conditions.
6. Specifications
| Feature | Specification |
|---|---|
| Model | AP-567EX (R4W66A) |
| Wi-Fi Standard | Wi-Fi 6 (802.11ax) |
| Antennas | Integrated Directional (90°H x 90°V) |
| Max Data Rate | 1.49 Gbps |
| Ethernet Port | 1x 10/100/1000BASE-T (PoE+) |
| Power Consumption | 15.6W max |
| Dimensions | 16.5 x 16.5 x 13 cm |
| Weight | 1.09 kg |
7. Advantages
- Superior environmental durability compared to standard outdoor APs
- Integrated IoT radio eliminates need for extra hardware
- Advanced security features including WPA3 and TPM
- Optimized for high-density client environments
- Centralized management via Aruba Central or on-prem controllers
8. Service & Support
We offer competitive pricing, reliable supply, and global shipping. All HPE Aruba Networking products come with a limited lifetime warranty. Our technical team provides 24/7 pre- and post-sales support, including integration assistance and configuration guidance.
9. Frequently Asked Questions
Q: What makes this AP suitable for hazardous locations?
A: It is certified for Class 1 Division 2 and ATEX Zone 2 environments, with a sealed enclosure and surge protection.
Q: Can it be powered via PoE?
A: Yes, it supports 802.3at PoE+ for both power and data.
Q: Does it support cloud management?
A: Yes, it is compatible with Aruba Central for cloud-based management.
10. Precautions
- Ensure proper grounding and surge protection in outdoor deployments.
- Use only approved mounting kits for secure installation.
- Verify regulatory domain settings for compliant RF operation.
- Do not disassemble the unit; tampering may void warranty and certifications.
